N
CLC426
Wideband, Low-Noise, Voltage Feedback Op Amp
General Description
The CLC426 combines an enhanced voltage-feedback architecture
with an advanced complementary bipolar process to provide a
high-speed op amp with very low noise (1.6nV/
√Hz&2.0pA/√Hz)and
distortion (-62/-68dBc 2nd/3rd harmonics at 1Vpp and 10MHz).
Providing a wide 230MHz gain-bandwidth product, a fast 400V/
s
slew rate and very quick 16ns settling time to 0.05% , the CLC426 is
the ideal choice for high speed applications requiring a very wide-
dynamic range such as an input buffer for high-resolution analog-to-
digital converters.
The CLC426 is internally compensated for gains
≥ 2V/V and can
easily be externally compensated for unity-gain stability in applications
such as wideband low-noise integrators. The CLC426 is also equipped
with external supply current adjustment which allows the user to
optimize power, bandwidth, noise and distortion performance for each
application.
The CLC426's combination of speed, low noise and distortion and low
dc errors will allow high-speed signal conditioning applications to
achieve the highest signal-to-noise performance. To reduce design
times and assist board layout, the CLC426 is supported by an
evaluation board and SPICE simulation model available from National.
For even higher gain-bandwidth voltage-feedback op amps see the
1.9GHz CLC425 (Av
≥ 10V/V) or the 5.0GHz CLC422 (A
v
≥ 30V/V).
June 1999
CLC426
Wideband,
Lo
w-Noise
,V
olta
g
e
Feedbac
k
Op
Amp
Features
s
Wide gain-bandwidth product: 230MHz
s
Ultra-low input voltage noise: 1.6nV/
√Hz
s
Very low harmonic distortion: -62/-68dBc
s
Fast slew rate: 400V/
s
Adjustable supply current
s
Dual ±2.5 to ±5V or single 5 to 12V supplies
s
Externally compensatable
Applications
s
Active filters & integrators
s
Ultrasound
s
Low-power portable video
s
ADC/DAC buffer
s
Wide dynamic range amp
s
Differential amps
s
Pulse/RF amp
Wide Dynamic Range
Sallen-Key Band Pass Filter
2nd-Order
(20MHz, Q=10, G=2)
1
2
3
4
NC
Vinv
Vnon-inv
-Vcc
Rp (optional)
+Vcc
Vout
Ext. Comp.
(optional)
8
7
6
5
-
+
Pinout
DIP & SOIC
Typical Application
1999 National SemiconductorCorporation
http://www.national.com
Printed in the U.S.A.
