Electrical characteristics
RHF43B
6/16
Doc ID 13477 Rev 7
VOH
High level output voltage
RL =1kΩ
+125°C
2.8
V
+25°C
2.9
2.95
-55°C
2.8
RL =10kΩ
+125°C
2.9
+25°C
2.94
2.98
-55°C
2.9
VOL
Low level output voltage
RL =1kΩ
+125°C
0.2
V
+25°C
0.05
0.1
-55°C
0.2
RL =10kΩ
+125°C
0.1
+25°C
0.02
0.06
-55°C
0.1
Iout
Output sink current
Vout = VCC
+125°C
15
mA
+25°C
20
30
-55°C
15
Output source current
Vout = VCC
+125°C
10
+25°C
15
25
-55°C
10
AC performance
GBP
Gain bandwidth product
F = 100 kHz
RL=1 kΩ, CL= 100 pF
+125°C
3.5
MHz
+25°C
6
7.5
-55°C
3.5
Fu
Unity gain frequency
RL=1 kΩ, CL= 100 pF
+25°C
5
MHz
φm
Phase margin
Gain = +5
RL=1 kΩ, CL= 100 pF
+25°C
50
Degrees
SR
Slew rate
RL=1 kΩ, CL= 100 pF
+125°C
1.7
V/
μs
+25°C
2
2.7
-55°C
1.7
en
Equivalent input noise voltage F = 1 kHz
+25°C
7
in
Equivalent input noise current F = 1 kHz
+25°C
0.8
THD+en Total harmonic distortion
Vout = (VCC-1 V)/5
Gain = -5.1
Vicm =VCC/2
+25°C
0.01
%
Table 4.
3 V supply: VCC = + 3 V, VDD = 0, load to VCC/2
(unless otherwise specified) (continued)
Symbol
Parameter
Test conditions
Ambient
temp.
Min.
Typ.
Max.
Unit
nV
Hz
------------
pA
Hz
------------
