3
SCD5921 Rev B Advanced 3/8/11
Aeroflex Plainview
ABSOLUTE MAXIMUM RATINGS
Parameter
Range
Units
Case Operating Temperature Range
-55 to +125
°C
Storage Temperature Range
-65 to +150
°C
Supply Voltage
(+VCC)
+6.0
V
Digital Input Overvoltage
(VEN, VA)
< VCC +0.4
> GND -0.4
V
Analog Input Overvoltage
(CH0-CH15)
< VCC +0.4
> GND -0.4
V
NOTICE: Stresses above those listed under "Absolute Maximums Rating" may cause permanent damage to the device. These are stress rating
only; functional operation beyond the "Operation Conditions" is not recommended and extended exposure beyond the "Operation Conditions" may
affect device reliability.
RECOMMENDED OPERATING CONDITIONS
Symbol
Parameter
Typical
Units
+VCC
Power Supply Voltage
3.3 to 5.0
V
VEN, VA
Logic Low Level
30% VCC
V
VEN, VA
Logic High Level
70% VCC
V
ELECTRICAL PERFORMANCE CHARACTERISTICS
(TC = -55°C TO +125°C, +VCC = +5V -- UNLESS OTHERWISE SPECIFIED)
Parameter
Symbol
Conditions
Min
Max
Units
Supply Current
(+VCC)
+ICC
EN = 30% VCC
0.5
2
mA
+ISBY
EN = 70% VCC
10
100
A
Address Input Current
(A0-A3)
IAL
VA = 30% VCC
+25°C
-5
5
nA
+125°C
-50
50
nA
IAH
VA = 70% VCC
+25°C
-5
5
nA
+125°C
-50
50
nA
Enable Input Current
(EN)
IENL
VEN = 30% VCC
+25°C
-5
5
nA
+125°C
-50
50
nA
IENH
VEN = 70% VCC
+25°C
-5
5
nA
+125°C
-50
50
nA
Input Leakage Current
(CH0-CH15)
+IINLK
VIN = +5V, VEN =70% VCC,
Output and all unused MUX inputs under test =
0V
+25°C
-5
5
nA
+125°C
-50
50
nA
Output Leakage Current
(VOUT)
+IOUTLK
Tri-state, VEN > 70% VCC
+25°C
-5
5
nA
+125°C
-20
20
nA
