Original Creation Date: 01/14/99
Last Update Date: 05/15/00
Last Major Revision Date: 01/14/99
MNLM158A-X-RH REV 0D1
MICROCIRCUIT DATA SHEET
LOW POWER, DUAL OPERATIONAL AMPLIFIER: ALSO AVAILABLE
GUARANTEED TO 50K RAD (Si) TESTED TO MIL-STD-883,
METHOD 1019.5
General Description
The LM158A consists of two independent, high gain, internally frequency compensated
operational amplifiers which were designed specifically to operate from a single power
supply over a wide range of voltages.
Operation from split power supplies is also
possible and the low power supply current drain is independent of magnitude of the power
supply voltage.
Application areas include transducer amplifiers, dc gain blocks and all the conventional
op amp circuits which now can be more easily implemented in single power supply systems.
For example, the LM158A can be directly operated off of the standard +5V DC power supply
voltage which is used in digital systems and will easily provide the required interface
electronics without requiring the additional + 15V DC power supplies.
NS Part Numbers
LM158AH-QMLV
LM158AH/883
LM158AHLQML
LM158AHLQMLV
LM158AJ-QMLV
LM158AJ/883
LM158AJLQML
LM158AJLQMLV
LM158AWG-QMLV
LM158AWG/883
LM158AWGLQML
LM158AWGLQMLV
Industry Part Number
LM158
Prime Die
LM158
Controlling Document
SEE FEATURES SECTION
Processing
MIL-STD-883, Method 5004
Quality Conformance Inspection
MIL-STD-883, Method 5005
Subgrp Description
Temp ( C)
o
1
Static tests at
+25
2
Static tests at
+125
3
Static tests at
-55
4
Dynamic tests at
+25
5
Dynamic tests at
+125
6
Dynamic tests at
-55
7
Functional tests at
+25
8A
Functional tests at
+125
8B
Functional tests at
-55
9
Switching tests at
+25
10
Switching tests at
+125
11
Switching tests at
-55
1
