Sockets
DIP Sockets
528-AG12D-ES
(Tyco Electronics P/N: 6-1437536-1)
Document links for this part cannot be displayed. Your browser does not support inline frames or
is currently configured not to display inline frames. Inline frames are supported in both Internet
Explorer 5 and Netscape 6, as well as all later versions of these browsers.
Related Part Information
General Information
eCommerce
Related Part Information
Photos & Line Drawings - The photographs and/or line drawings are representative images of a
product for viewing purposes only.
Searchable Features:
Brand:
AMP
RoHS/ELV Compliance:
Non-compliant
Lead Free Solder
Process:
Reflow solder
capable to 245°C
Product Type:
DIP Socket
No. of Positions:
28
Row-to-Row Spacing
(mm [in]):
15.24 [0.600]
Contact Mount:
Thru Hole
Mount Style:
Vertical
Centerline (mm [in]):
2.54 [0.100]
Profile:
Standard
Frame Style:
Closed
Leg Style:
Straight
Contact Material:
Beryllium Copper
Other Properties:
Insulation Resistance
(MΩ):
5,000
Contact Resistance
(mO):
10
Sleeve Material:
Brass/Copper
Contact Termination
Area Plating:
Tin-Lead
Product Series:
500 Series
