6-1734531-0 Product Details
Product View
6-1734531-0
T E I nternal N umber: 6 -1 7 3 4 5 3 1 -0
2mm AMPMODU
Product Highlights:
l
Receptacle
l
PCB Mount Style = Through Hole
l
Not Shrouded
l
Number of Positions = 60
l
No PCB Retention Feature
Quick Links
Documentation & Additional Information
Product Drawings:
l
AMPMODU 2.0mm PITCH, RCPT CONN., RIGHT ANGLE, MOUNT... (PDF, English)
Catalog Pages/Data Sheets:
l
AMPMODU_INTERCONNEC TION_SYSTEM_SEC TION3AND4 (PDF, English)
Product Specifications:
l
AMPMODU 2.0MM PITCH BOARD TO BOARD CONNEC TOR. (PDF, English)
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
Additional Information:
l
Related Products:
l
Product Features (Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type = Receptacle
l
PCB Mount Style = Through Hole
l
Shrouded = No
l
Number of Positions = 60
l
PCB Retention Feature = No
l
PCB Mount Angle = Right Angle
l
Keyed = No
l
Holddown Feature = Without
l
PCB Thickness (mm [in]) = 1.57 [0.062]
l
Post Size (mm [in]) = 0.50 [.020]
Electrical Characteristics:
l
Voltage (VAC) = 200
l
Contact Current Rating (Amps.) = 1
l
Insulation Resistance (M?) = 1,000
Termination Related Features:
l
Termination Post Length (mm [in]) = 3.00 [0.118]
l
Solder Tail Contact Plating = Tin over Nickel
Body Related Features:
l
Selectively Loaded = No
l
Post Number(s) Omitted = None
l
Centerline, Matrix (mm [in]) = 2.00 x 2.00 [.079 x .079]
l
Mating Pin-to-PCB Dimension (mm [in]) = 1.50 [0.059]
l
Mount Type = Printed Circuit Board
l
Number of Rows = Dual
l
Cover = Without
l
UL Rating = UL 94V-0
Contact Related Features:
l
Contact Mating Area Plating Material = Gold (10)
l
Contact Base Material = Phosphor Bronze
l
Approved Standards = UL E28476, CSA LR7189
Housing Related Features:
l
Housing Material = Thermoplastic
l
Dielectric Strength (VAC) = 650
l
Housing Flammability Rating = UL 94V-0
l
Housing Color = Black
l
Housing Entry Style = Closed Top
Configuration Related Features:
l
Stack Height (mm [in]) = 4.85 [0.191]
Industry Standards:
l
RoHS/ELV Compliance = RoHS compliant, ELV compliant
l
Lead Free Solder Processes = Wave solder capable to 240?C , Wave
solder capable to 260?C , Wave solder capable to 265?C
l
RoHS/ELV Compliance History = Always was RoHS compliant
Conditions for Usage:
l
Temperature Range (?C) = -40 – +105
Packaging Related Features:
l
Packaging Method = Tube
Other:
l
Brand = Tyco Electronics
