Home
>
Products
>
By Type
>
PCB Connectors - Wire to Board - Power
>
Product Feature Selector
> Product Details
644889-5 Product Details
Product View
644889-5
TE Internal Number: 644889-5
Superseded
Contact Product Information Center
MTA, CST-100 II, MT-6 and SL Connectors and Headers
Always EU RoHS/ELV Compliant
(
Statement of Compliance
)
Product Highlights:
l
MTA-100 Connectors
l
Number of Positions = 5
l
Mating Type = Header
l
Wire-to-Board Application
l
2.54 mm Contact Centerline Spacing
View all Features
Check Pricing & Availability
Search for Tooling
Product Feature Selector
Contact Us About This Product
Quick Links
A dd to My Part List
Request Sample
Find Similar Products
Buy Product
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type
= MTA-100 Connectors
l
Number of Positions
= 5
l
Mating Type
= Header
l
PCB Mount Angle
= Right Angle
l
PCB Retention Feature = No
l
Mating Polarization
= Without
l
Mating Connector Lock = Without
l
Four Points of Contact
= Without
l
Shrouded
= No
l
Mounting Ears
= Without
l
Post Size (mm [in]) = 0.64 [.025]
l
Comment = Headers without retentive legs are suitable for
breakaway application
Mechanical Attachment:
l
Panel Attachment
= Without
Electrical Characteristics:
l
Voltage Rating (VAC) = 250
Termination Related Features:
l
Solder Tail Contact Plating
= Tin
Body Related Features:
l
Narrow
= Yes
l
Post Number(s) Omitted
= None
Contact Related Features:
l
Contact Centerline Spacing (mm [in])
= 2.54 [0.100]
l
Contact Shape
= Square
l
Contact Mating Area Plating Material
= Gold (15)
l
Contact Base Material
= Copper Alloy
Housing Related Features:
l
Housing Color = White
l
Housing Flammability Rating = UL 94V-0
l
Housing Material = Polyester
Configuration Related Features:
l
Backwall/Post Interruption(s)
= Without
Industry Standards:
l
RoHS/ELV Compliance
= RoHS compliant, ELV compliant
l
Lead Free Solder Processes
= Wave solder capable to 240C
l
RoHS/ELV Compliance History = Always was RoHS compliant
Conditions for Usage:
l
Terminate To
= Printed Circuit Board
Operation/Application:
l
Application
= Wire-to-Board
Other:
l
Brand = AMP
