646352-1 Product Details
Product Photo
646352-1
TE Internal Number: 646352-1
Superseded
Search for Replacement Parts
2mm Hard Metric PCB Mount Connectors (Z-PACK 2mm HM)
Not reviewed for RoHS Compliance
Product Highlights:
l
Connector
l
Connector Type = Type A
l
Receptacle
l
Interface Type = 2mm HM
l
Contact Type = Signal
View all Features
Check Pricing & Availability
Search for Tooling
Product Feature Selector
Contact Us About This Product
Quick Links
A dd to My Part List
Request Sample
Find Similar Products
Buy Product
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
Connector, Z-PACK, 8 Row, 2mm HM
(PDF, English)
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
List all Documents
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type
= Connector
l
Connector Type
= Type A
l
Gender
= Receptacle
l
Number of Positions
= 176
l
PCB Mount Angle
= Right Angle
l
Mating Polarization
= With
l
Mating Polarization Type
= Multi-Purpose Center
l
Shielded
= No
Mechanical Attachment:
l
Board Mount
= Free Board
l
Module Length (mm [in])
= 50.00 [1.968]
l
Crosstalk Version
= Standard
l
AMP Standard Option Number = 1
Termination Related Features:
l
Interface Type
= 2mm HM
l
Termination End Plating = Tin-Lead over Nickel
Body Related Features:
l
Number of Rows
= 8
l
Grounding Contact
= Without
l
Rows Loaded = A, H, G, F, E, B, C, D
Contact Related Features:
l
Contact Type
= Signal
l
Feedthrough Post Length (mm [in])
= 3.30 [0.130]
l
CompactPCI
= Yes
l
Contact Mating Area Plating Material
= Gold (30)
l
Contact Base Material = Phosphor Bronze
Housing Related Features:
l
Housing Material = Polyester GF
l
Housing Color = Gray
l
Housing Flammability Rating = UL 94V-0
Industry Standards:
l
RoHS/ELV Compliance
= Not reviewed for ELV/RoHS compliance
l
Lead Free Solder Processes
= Not reviewed for lead free solder
process
Packaging Related Features:
l
Packaging Quantity = 11
Other:
l
Brand = AMP
