SURFACE MOUNT CHIP LED LAMPS
Top View LEDs With Bi-Color
Part Number: 67-22SURSYGC
Package outlines & Re-flow Profile
A-BRIGHT INDUSTRIAL CO., LTD.
Soldering iron
Basic spec is
U
5sec when 260
℃
. If temperature is higher,
time should be shorter (+10
℃
-1sec ).Power dissipation
of iron should be smaller than 15W, and temperatures
should be controllable .Surface temperature of the device
should be under 230
℃
.
Reflow Temp/Time
ITEM
MATERIALS
Resin (mold)
Epoxy
Lens color
Water Clear
Printed circuit board
BT
SUR
AlGaInP
Hyper Red
Material
&
Emitted color SYG
AlGaInP
Super Yellow Green
