Document Number: 84732
For technical questions, contact: optocoupleranswers@vishay.com
www.vishay.com
Rev. 1.5, 08-Apr-11
1
This document is subject to change without notice.
THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc?91000
High Speed Optocoupler, Single and Dual, 10 MBd
6N137, VO2601, VO2611, VO2630, VO2631, VO4661
Vishay Semiconductors
DESCRIPTION
The 6N137, VO2601, and VO2611 are single channel
10 MBd optocouplers utilizing a high efficient input LED
coupled with an integrated optical photodiode IC detector.
The detector has an open drain NMOS-transistor output,
providing less leakage compared to an open collector
Schottky clamped transistor output. The VO2630, VO2631,
and VO4661 are dual channel 10 MBd optocouplers. For the
single channel type, an enable function on pin 7 allows the
detector to be strobed. The internal shield provides a
guaranteed common mode transient immunity of 5 kV/μs for
the VO2601 and VO2631 and 15 kV/μs for the VO2611 and
VO4661. The use of a 0.1 μF bypass capacitor connected
between pin 5 and 8 is recommended.
FEATURES
Choice of CMR performance of 15 kV/μs,
5 kV/μs, and 100 V/μs
High speed: 10 MBd typical
+ 5 V CMOS compatibility
Pure tin leads
Guaranteed AC and DC performance over
temperature: - 40 °C to + 100 °C temperature
range
Meets IEC 60068-2-42 (SO2) and IEC 60068-2-43 (H2S)
requirements
Low input current capability: 5 mA
Compliant to RoHS Directive to 2002/95/EC and in
accordance WEEE 2002/96/EC
APPLICATIONS
Microprocessor system interface
PLC, ATE input/output isolation
Computer peripheral interface
Digital fieldbus isolation: CC-link, DeviceNet, profibus,
SDS
High speed A/D and D/A conversion
AC plasma display panel level shifting
Multiplexed data transmission
Digital control power supply
Ground loop elimination
AGENCY APPROVALS
UL1577, file no. E52744 system code H, double protection
cUL - file no. E52744, equivalent to CSA bulletin 5A
DIN EN 60747-5-5 (VDE 0884) available with option 1
BSI IEC 60950
1
2
3
4
8
7
6
5
1
2
3
4
8
7
6
5
NC
A
C
NC
V
CC
V
E
VO
GND
A1
C1
C2
A2
V
CC
VO1
VO2
GND
Single channel
Dual channel
6N137, VO2601, VO2611
VO2630, VO2631, VO4661
18921-30
V
DE
18921-15
ORDERING INFORMATION
V
O
26
01
-
X
0
#
T
PART NUMBER
PACKAGE OPTION
TAPE
AND
REEL
AGENCY CERTIFIED/PACKAGE
CHANNELS 1
CHANNELS 2
CMR (kV/μs)
BSI, UL, cUL
0.1
5
15
0.1
5
15
DIP-8
6N137
VO2601
VO2611
VO2630
VO2631
VO4661
DIP-8, 400 mil, option 6
6N137-X006
VO2601-X006
VO2611-X006
VO2630-X006
VO2631-X006
VO4661-X006
SMD-8, option 7
6N137-X007T
VO2601-X007T VO2611-X007T VO2630-X007T VO2631-X007T VO4661-X007T
VDE, BSI, UL, cUL
0.1
5
15
0.1
5
15
DIP-8, 400 mil, option 6
-
VO2601-X016
VO2611-X016
-
SMD-8, option 7
-
VO2601-X017T VO2611-X017T
-
VO2631-X017T
-
10.16 mm
> 0.7 mm
7.62 mm
DIP-8
Option 7
Option 6
