參數資料
| 型號： | 7-1437554-2 |
| 廠商： | TYCO ELECTRONICS ALCOSWITCH |
| 元件分類： | 開關 |
| 英文描述： | TOGGLE SWITCH, SPDT, LATCHED, 0.02A, 20VDC, THROUGH HOLE-STRAIGHT |
| 文件頁數： | 1/1頁 |
| 文件大小： | 112K |
| 代理商： | 7-1437554-2 |
Electronic Components | Segments | Who We Are
Searc h
A103SYCB Product Details
Product View
A103SYCB
(7-1437554-2)
T E I nternal N umber: 7 -1 4 3 7 5 5 4 -2
Toggle Switches
Product Highlights:
l
A Series
l
Single Pole - Double Throw Configuration (Pole-Throw)
l
Current Rating = 0.4 VA Amps.
l
Mount Style = Through-Hole
l
Termination Type = Printed Circuit, Vertical
Quick Links
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
ALCOSWITCH PRODUCTS (PDF, English)
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
Additional Information:
l
Additional Product Images:
l
Related Products:
l
Product Features (Please use the Product Drawing for all design activity)
Product Type Features:
l
Configuration (Pole-Throw) = Single Pole - Double Throw
l
Termination Type = Printed Circuit, Vertical
Electrical Characteristics:
l
Current Rating (Amps.) = 0.4 VA
Termination Related Features:
l
Seal Type = Terminal Seal (epoxy)
Body Related Features:
l
Series = A
l
Mount Style = Through-Hole
l
Flammability Rating = UL 94V-0
Contact Related Features:
l
Contact Plating = Gold
Housing Related Features:
l
Toggle Style = Baton Long
l
Toggle Length (mm [in]) = 10.40 [0.410]
l
Process Sealed = No
l
Bushing Style = Threaded
l
Bushing Type = 1/4-40
Configuration Related Features:
l
Operating Function = On Off On
Industry Standards:
l
RoHS/ELV Compliance = Not ELV/RoHS compliant
l
Lead Free Solder Processes = Wave solder capable to 240?C
Other:
l
Brand = Alcoswitch
