74VHC245
OCTAL BUS
TRANSCEIVER (3-STATE)
PRELIMINARY DATA
May 1998
ORDER CODES :
74VHC245M
74VHC245T
M
(MicroPackage)
I
HIGH SPEED:t
PD
= 4.0 ns(TYP.) at V
CC
=5V
I
LOWPOWER DISSIPATION:
I
CC
= 4
μ
A (MAX.) at T
A
=25
o
C
I
HIGH NOISEIMMUNITY:
V
NIH
=V
NIL
=28%V
CC
(MIN.)
I
SYMMETRICALOUTPUT IMPEDANCE:
|I
OH
| = I
OL
=8 mA (MIN)
I
BALANCED PROPAGATIONDELAYS:
t
PLH
t
PHL
I
OPERATINGVOLTAGERANGE:
V
CC
(OPR)= 2Vto5.5V
I
PIN AND FUNCTION COMPATIBLEWITH
74SERIES245
I
IMPROVEDLATCH-UP IMMUNITY
I
LOWNOISEV
OLP
=0.9V(Max.)
DESCRIPTION
The 74VHC245 is an advanced high-speed
CMOS OCTAL BUS TRANSCEIVER (3-STATE)
fabricated with sub-micron silicon gate and
double-layer metal wiring C
2
MOS technology. It
has similar high speed performance of equivalent
Bipolar Schottky TTL combined with true CMOS
low power dissipation.
This IC is intended for two-way asynchronous
communication
between
direction of data trasmission is determined by the
data
busses;
the
T
(TSSOP Package)
level of the DIR input. The enable input G can be
used to disable the device so that the busses are
effectivelyisolated.
All
inputs and
outputs
protectioncircuits against static discharge, giving
them 2KV ESD immunity and transient excess
voltage.
IT IS PROHIBITED TO APPLY A SIGNAL TO A
TERMINAL WHEN IT IS IN OUTPUT MODE
AND WHEN A BUS TERMINAL IS FLOATING
(HIGH IMPEDANCE STATE) IT IS REQUESTED
TO FIX THE INPUT LEVEL BY MEANS OF
EXTERNAL
PULL
DOWN
RESISTOR.
are
equipped with
OR
PULL
UP
PINCONNECTION AND IEC LOGICSYMBOLS
1/8
