| 型號： | 8-1437565-8 |
| 廠商： | TYCO ELECTRONICS ALCOSWITCH |
| 元件分類： | 開關 |
| 英文描述： | KEYPAD SWITCH, SPST, MOMENTARY-TACTILE, 0.05A, 24VDC, 2.55 N, THROUGH HOLE-RIGHT ANGLE |
| 封裝： | ROHS COMPLIANT |
| 文件頁數： | 1/1頁 |
| 文件大小： | 116K |
| 代理商： | 8-1437565-8 |
Electronic Components | Segments | Who We Are
Searc h
FSMRA2JA Product Details
Product View
FSMRA2JA
(8-1437565-8)
T E I nternal N umber: 8 -1 4 3 7 5 6 5 -8
Pushbutton Switches
Product Highlights:
l
Switch - Mechanical
l
Tactile
l
Single Pole - Single Throw Configuration (Pole-Throw)
l
Contact Rating = 50mA
l
Operating Function = Off [On]
Quick Links
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
ALCOSWITCH PRODUCTS (PDF, English)
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files: (CAD Format & Compression Information)
l
2D Drawing (DXF, Version M)
l
3D Model (IGES, Version M)
l
3D Model (STEP, Version M)
Additional Information:
l
Related Products:
l
Product Features (Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type = Switch - Mechanical
l
Tactile = Yes
l
Configuration (Pole-Throw) = Single Pole - Single Throw
l
Mount Angle = Right Angle
l
Termination Type = Printed Circuit
l
Actuator Style = Round
l
Comment = (On) indicates momentary position.
Electrical Characteristics:
l
Contact Rating = 50mA
Body Related Features:
l
Series = FSMRAJ
l
Mount Style = Through-Hole
l
Actuator Length (mm [in]) = 1.24 [0.049]
l
Actuator Profile = Extended
l
Actuator Color = Black
l
Case Material = Polyamide
l
Actuator Material = Polyacetal Resin
Contact Related Features:
l
Contact Plating = Silver
l
Contact Base Material = Copper Alloy
Housing Related Features:
l
Process Sealed = No
l
Low Profile = No
Configuration Related Features:
l
Operating Function = Off [On]
l
Ganged = No
l
ESD Grounding Terminal = Without
l
Actuator Force (g [oz]) = 260.00 [9.178]
l
Number of Actuators = Single
l
Illuminated = No
l
Dust Proof = No
l
Support Bracket = Without
l
Snap Action = Without
l
Tactile Feel = With
l
Switch Height (mm [in]) = 3.86 [0.152]
Industry Standards:
l
RoHS/ELV Compliance = RoHS compliant, ELV compliant
l
Lead Free Solder Processes = Wave solder capable to 240?C
l
RoHS/ELV Compliance History = Always was RoHS compliant
Conditions for Usage:
l
Temperature Rating = Standard
Packaging Related Features:
l
Packaging Method = Loose Piece
Other:
l
Brand = Alcoswitch
