Product catalogue | Industrial Ethernet | Passive components | Copper cable | Patch Cables | Patch Cables Cat.6 LSZH
gerade
- 1 -
General ordering data
Order No.
8867490000
Part designation
IE-C6FP8LD0700A40A40-D
Version
, Cat.6 (IEC 11801), RJ45 IP20, RJ45 IP20, S/
FTP, LSZH
EAN
4032248593682
Qty.
1 pc(s).
Cable plug
Plug left
RJ45 IP20
Plug right
RJ45 IP20
Cable
Application
Patch cable
Length
70 m
Category
Cat.6 (IEC 11801)
Shielding
S/FTP
Cross-section
4*2*AWG 27/7 - 4*2*0.1 mm
Sheath material
LSZH
Diameter of copper/core
0.43 mm
Cladding diameter, min.
5.5 mm
Cladding diameter, max.
5.9 mm
Sheathing colour
light grey (RAL 7035)
Wire insulation diameter
1.04 mm
Free from halogens
to IEC 60754-2
Resistance to spread of flame
gem IEC 60332-1 / UL 1581 FT2
Resistance to oils
to IEC 60811-2-1
Min. bending radius, once only
25 mm
Min. bending radius, repetitive
50 mm
Operating temperature, min.
-20 °C
Operating temperature, max.
60 °C
Installation temp., min.
0 °C
Installation temp., max.
50 °C
Storage temperature, max.
60 °C
Storage temperature, min.
-20 °C
Classifications
ETIM 2.0
EC001262
ETIM 3.0
EC001262
eClass 5.1
27-06-03-90
Similar products
Order No.
Part designation
Version
8808830000
IE-C6FP8LD0005A40A40-D
Patch cable, Cat.6 (IEC 11801), RJ45 IP20, RJ45 IP20, S/FTP,
LSZH
8808840000
IE-C6FP8LD0010A40A40-D
Patch cable, Cat.6 (IEC 11801), RJ45 IP20, RJ45 IP20, S/FTP,
LSZH
8808850000
IE-C6FP8LD0020A40A40-D
Patch cable, Cat.6 (IEC 11801), RJ45 IP20, RJ45 IP20, S/FTP,
LSZH
