- 您現在的位置：買賣IC網 > PDF目錄24573 > 9-1393224-8 POWER/SIGNAL RELAY, SPST, MOMENTARY, 0.044A (COIL), 5VDC (COIL), 220mW (COIL), 8A (CONTACT), THROUGH HOLE-STRAIGHT MOUNT PDF資料下載
參數資料
| 型號： | 9-1393224-8 |
| 元件分類： | 功率/信號繼電器 |
| 英文描述： | POWER/SIGNAL RELAY, SPST, MOMENTARY, 0.044A (COIL), 5VDC (COIL), 220mW (COIL), 8A (CONTACT), THROUGH HOLE-STRAIGHT MOUNT |
| 封裝： | ROHS COMPLIANT |
| 文件頁數： | 3/4頁 |
| 文件大小： | 125K |
| 代理商： | 9-1393224-8 |
Documentation & Additional Information
Product Drawings:
None Available
Catalog Pages/Data Sheets:
Miniature Power PCB Relay RYII (PDF, English)
Product Specifications:
None Available
Application Specifications:
None Available
Instruction Sheets:
None Available
CAD Files:
None Available
List all Documents
Additional Information:
Product Line Information
Related Products:
Tooling
Product Features (Please use the Product Drawing for all design activity)
Product Type Features:
Termination Type = Through Hole
Electrical Characteristics:
Contact Current Rating (Amps.) = 8
Coil Resistance () = 112
Coil Power, Nominal (mW) = 220
Actuating System = DC
Coil Power, Nominal (W) = 0.22
Input Voltage (VDC) = 5
Dielectric Strength - Coil Contacts (V rms) = 5000
Tracking Resistance of Relay Base = PTI250
Coil Rating = Sensitive
Body Related Features:
Series = RYII
Polarized = No
Enclosure Color = Orange
Housing Related Features:
Version = Pinning 5mm, Version for IEC 60335-1
(domestic appliances)
Pick-Up (V) = 3.5
Drop-Out (V) = 0.5
Configuration Related Features:
Contact Arrangement = 1 Form B, SPST-NC, 1 N/C
Coil Magnetic System = Monostable
Coil Suppression Diode = Without
Coil Selection Criteria = Nominal Voltage
Coil Latching = Without
Status Indicator = None
Number of Coils = 1
Industry Standards:
RoHS/ELV Compliance = RoHS compliant, ELV
compliant
