參數資料
| 型號： | 9-1393812-3 |
| 元件分類： | 功率/信號繼電器 |
| 英文描述： | POWER/SIGNAL RELAY, DPST, MOMENTARY, 0.038A (COIL), 24VDC (COIL), 1000mW (COIL), 5A (CONTACT), 250VDC (CONTACT), PANEL MOUNT |
| 封裝： | ROHS COMPLIANT |
| 文件頁數： | 4/11頁 |
| 文件大小： | 415K |
| 代理商： | 9-1393812-3 |
Features
– Stronger magnet system and thus wider voltage range
than cradle relay N
– highly reliable
– Contacts for signal loads and currents up to 5 A
– AC and DC, latching and non-latching,
coils operating voltage 6 V ... 220 V
– Multi purpose relay
– great variety of contact arrangements and materials to
meet specific applications
– Sockets for easy and quick mounting of relays (see data
sheet Accessories)
Typical applications
– Press controls with high safety requirements
(forcibly guided springs)
– Traffic and railroad signalling engineering
– Motor vehicle traffic controls
Cradle Relay S
V23054
Hand solder and plug-in relay,
for DC operation,
non-polarized, non-latching
Versions
– Size I, II or III, depending on contact set
– Standard contact sets with max. 6 changeover contacts
or 6 make contacts
– Single or bifurcated contacts
– Hand solder terminals also for plug-in connection with
screw fixing
– Dust-protected
Page 2 (11)
108-98014 Rev. B
European Directive conformance:
Cradle S relay product conformance according to:
-
Directive 2000/53/EC: ELV (End of Life of Vehicles)
-
Directive 2002/95/EC: ROHS (Restrictions of the
use of certain hazardous substances in electrical and
electronic equipment)
Compliance is evidenced by written declaration from all raw
material suppliers.
Tyco Electronics AXICOM only has responsibility for the proper
processing of these materials.
Confirmation is valid for date codes ≥ 0501
