9-1415027-1 Product Details
9-1415027-1
Active
Powe r PC Board Re lays
Converted to EU RoHS/ELV Compliant
(Statement of Compliance)
Product Highlights:
RT1 Inrush Series
Contact Arrangement = 1 Form A, SPST-NO, 1 N/O
Contact Current Rating = 16 Amps.
Monostable Coil Magnetic System
Without Coil Suppression Diode
View all Features | Find Similar Products
Previous 1 ... 11 12 13 [14] 15 ... 20 Next
Quick Links
Check Pricing & Availability
Search for Tooling
Product Feature Selector
Compare Products
Contact Us About This Product
Documentation & Additional Information
Product Drawings:
None Available
Catalog Pages/Data Sheets:
Power PCB Relay RT1 Inrush (PDF, English)
Product Specifications:
None Available
Application Specifications:
None Available
Instruction Sheets:
None Available
CAD Files:
None Available
List all Documents
Additional Information:
Product Line Information
Related Products:
Tooling
Product Features
(Ple ase u se th e Produ ct Drawin g for all de sign activity)
Product Type Features:
Termination Type = Through Hole
Electrical Characteristics:
Contact Current Rating (Amps.) = 16
Coil Resistance (?) = 8570
Coil Power, Nominal (mW) = 400
Actuating System = DC
Coil Power, Nominal (W) = 0.40
Input Voltage (VDC) = 60
Dielectric Strength - Coil Contacts (V rms) = 5000
Tracking Resistance of Relay Base = PTI250
Coil Rating = Sensitive
Body Related Features:
Series = RT1 Inrush
Polarized = No
Enclosure Color = Orange
Contact Related Features:
Mounting Options = PC Board, Socket
Enclosure = Flux-Tight
FCC Part 68 Isolation = No
Relay Type = PCB
Contact Material = Silver Nickel 90/10
Approx. Dimensions (L x W x H) (mm [in]) = 29.00 x 12.70 x 15.70 [1.142
x .500 x .618]
Contact Type = Single
Pin Configuration = Industry Standard 5mm
Housing Related Features:
Version = High Inrush Current, 80A
Pick-Up (V) = 42
Drop-Out (V) = 6
Configuration Related Features:
Contact Arrangement = 1 Form A, SPST-NO, 1 N/O
Coil Magnetic System = Monostable
Coil Suppression Diode = Without
Coil Selection Criteria = Nominal Voltage
Coil Latching = Without
LED Indicator = Without
Number of Coils = 1
Industry Standards:
RoHS/ELV Compliance = RoHS compliant, ELV compliant
Lead Free Solder Processes = Wave solder capable to 240C, Wave solder
capable to 260C, Wave solder capable to 265C
RoHS/ELV Compliance History = Converted to comply with RoHS
directive
Coil Insulation Classification = UL Class F
Packaging Related Features:
Packaging Method = Carton Bar
Other:
Electrical Spacing = 10.0mm Clearance 10.0mm Creepage
