14-Bit, 10 MSPS Monolithic A/D Converter with LPT ASIC
9240LP
03.08.02 Rev 4
TABLE 1. 9240LP PIN DESCRIPTION
PIN NUMBER
NAME
DESCRIPTION
1
DVSS
Digital Ground
2, 29
AVSS
Analog Ground
3
DVDD
5V Digital Supply
4, 28
AVDD
5V Analog Supply
5
NC
No Connect
6
DRVDD
Digital Output Driver Supply
7
CLK
Clock Input Pin
8
LPTSTATUS
A 0 to 5V pulse is output during the decision
time and protect time. Normally low.
9
LPTBIT
The LPT circuit will crowbar the power supplies
to the 9240LP for as long as a logic high is
applied. Used to verify operation of the LPT.
Normally a logical low or ground is applied to
this input.
10
NC
No Connect
11
BIT 14
Least Significant Data Bit (LSB)
12-23
BIT 13-BIT 2
Data Output Bits
24
BIT 1
Most Significant Data Bits (MSB)
25
OTR
Out of Range
26, 27, 30
NC
No Connect
31
SENSE
Reference Select
32
V
REF
Reference I/O
33
REFCOM
Reference Common
34, 38
NC
No Connect
35
BIAS
Power/Speed Programming
36
CAPB
Noise Reduction Pin
37
CAPT
Noise Reduction Pin
39
CML
Common-Mod Level (Midsupply)
40
LPTV
REF
Protected Reference I/O
41
V
INA
Analog Input Pin (+)
42
V
INB
Analog Input Pin (-)
43
LPTDVDD
Protected 5V Digital Supply
44
LPTAVDD
Protected 5V Analog Supply
