Philips Semiconductors - PIP - NE/SA/SE555/SE555C; Timer
Product Information
NE/SA/SE555/SE555C;
Timer
Information as of 2003-04-22
Stay informed
Download datasheet
topGeneral description
DESCRIPTION The 555 monolithic timing circuit is a highly stable controller capable of producing accurate time delays, or oscillation. In the time
delay mode of operation, the time is precisely controlled by one external resistor and capacitor. For a stable operation as an oscillator, the free
running frequency and the duty cycle are both accurately controlled with two external resistors and one capacitor. The circuit may be triggered and
reset on falling waveforms, and the output structure can source or sink up to 200 mA.
topFeatures
q
Turn-off time less than 2 us
q
Max. operating frequency greater than 500 kHz
q
Timing from microseconds to hours
q
Operates in both astable and monostable modes
q
High output current
q
Adjustable duty cycle
q
TTL compatible
q
Temperature stability of 0.005pct per Cel
file:///G|/imaging/BITTING/CPL/20030424/04232003_9/PHGL/_HTML04232003/NE555N.html (1 of 4) [Apr-25-2003 3:14:55 PM]
