參數資料
| 型號： | 934031250115 |
| 廠商： | NXP SEMICONDUCTORS |
| 元件分類： | 二極管(射頻、小信號、開關、功率) |
| 英文描述： | 0.25 A, 125 V, SILICON, SIGNAL DIODE |
| 封裝： | HERMETIC SEALED, GLASS, SMD, 2 PIN |
| 文件頁數： | 5/8頁 |
| 文件大小： | 49K |
| 代理商： | 934031250115 |
1999 May 28
5
Philips Semiconductors
Product specication
Low-leakage diode
BAS45AL
VR = 125 V.
Fig.5
Reverse current as a function of junction
temperature.
handbook, halfpage
10 4
10
3
10 2
10
10 1
150
50
0
MBD456
100
1
I R
(nA)
T ( C)
o
j
typ
max
Fig.6
Diode capacitance as a function of reverse
voltage; typical values.
f = 1 MHz; Tj =25 °C.
handbook, halfpage
010
20
15
5
3
2
0
1
MBG524
VR (V)
Cd
(pF)
handbook, full pagewidth
t rr
(1)
I F
t
output signal
t r
t
t p
10%
90%
VR
input signal
V = V
I x R
RF
S
R = 50
S
IF
D.U.T.
R = 50
i
SAMPLING
OSCILLOSCOPE
MGA881
Fig.7 Reverse recovery time test circuit and waveforms.
