Philips Semiconductors
Product specification
Damper-Modulator
BYM358X
fast, high-voltage
FEATURES
SYMBOL
QUICK REFERENCE DATA
Low forward volt drop
DAMPER
MODULATOR
Ultra fast switching
Soft recovery characteristic
V
R=1500 V
V
R=600 V
High thermal cycling
performance
V
F ≤ 1.5 V
V
F ≤ 1.08 V
Isolated mounting tab
I
F(peak) =7 A
I
F(peak) = 7 A
I
FSM ≤ 66 A
I
FSM ≤ 70 A
t
rr ≤ 170 ns
t
rr ≤ 60 ns
GENERAL DESCRIPTION
PINNING
SOT186A
Combined damper and modulator
PIN
DESCRIPTION
diodes
in
an
isolated
plastic
envelope for horizontal deflection in
1
damper cathode
PC monitors.
The BYM358X contains diodes
2
common anode/cathode
with performance characteristics
designed specifically for
3
modulator anode.
applications from 32kHz to 120kHz
The BYM358X series is supplied in
the conventional leaded SOT186A
package.
LIMITING VALUES
T
j = 25 C unless otherwise stated
DAMPER
MODULATOR
SYMBOL
PARAMETER
CONDITIONS
MIN
MAX
MIN
MAX
UNIT
V
RSM
Peak non-repetitive reverse
-
1500
-
600
V
voltage.
V
RRM
Peak repetitive reverse voltage
-
1500
-
600
V
RWM
Crest working reverse voltage
-
1300
-
600
V
I
F(peak)
Peak forward current
31-70 kHz monitor.
-
7
-
7
A
I
F(RMS)
RMS forward current
sinusoidal;a=1.57
-
15.7
-
14.1
A
I
FSM
Peak non-repetitive forward
t = 10 ms
-
60
-
70
A
current
t = 8.3 ms
-
66
-
77
A
sinusoidal;with
reapplied
V
RWM(MAX)
T
stg
Storage temperature
-40
150
-40
150
C
T
J
Operating junction temperature
-
150
-
150
C
1
3
2
damper
modulator
12 3
case
March 2000
1
Rev 1.000
