Philips Semiconductors - PIP - SA57254-XX; CMOS switching regulator (PWM controlled)
Search
Product Information
SA57254-XX; CMOS
switching regulator
(PWM controlled)
Information as of 2002-08-07
Stay informed
Download datasheet
Block diagram
Parametrics
topGeneral description
The SA57254-XX is a fully integrated DC/DC converter circuit. Efficient, compact power conversion is
achieved with a pulse width modulation (PWM) controlled switching regulator circuit designed using
CMOS processing. Low ripple and high efficiency of typically 83pct are achieved through PWM control.
The regulator has a high precision output with +-2.4pct accuracy. Few external components are required.
The SA57254-XX has a built-in soft-start circuit which reduces inrush current and voltage overshoot during
start-up. A low resistance CMOS power FET, which has low leakage current and low parasitic capacitance,
is on-chip.
topFeatures
q
Operates from 0.7 to 9 V DC
q
Ultra low operating supply currenttypically 17 mA
q
Built-in power FET
q
High efficiency-typically 83pct
q
High precision output-typically +-2.4pct
q
Operating temperature range of -40 to +85 Cel
q
Available output voltages: 2.0, 2.5, 2.8, 3.0, 3.3, 3.6, 5.0 V DC
q
Available in SOT23-5 surface mount package
topApplications
q
Mobile and portable phones
q
Instrumentation and industrial products
q
Other portable, battery-operated equipment
file:///G|/imaging/BITTING/cpl_IMAGES/PhilipsSe...54-XX;CMOSswitchingregulator(PWMcontrolled).htm (1 of 3) [Aug-28-2002 9:21:24 AM]
