ProductNumber:940-44-028-24-000000
Description:
PLCC Socket
Standard
Non-Lubricated
Through Hole
PlatingCode:
44
ShellPlating:
200 μ" Tin (matte finish) over 100
μ" Nickel
InnerContactPlating:
100 μ" Tin (matte finish) over 50 μ"
Nickel
Packaging:
Packaged in Tubes
#
Of
Pins
A
B
C
Qty.
per
Tube
Mill-Max
Part
Number
RoHS
Compliant
28
0.720
0.300
0.500
33
940-44-028-24-000000
INSULATORINFORMATION:
PPS (Ryton R-4-200)
High Temperature
PropertiesofPPS:
Brand: Ryton
Grade: R-4-200
Material Heat Deflection Temp. (per ASTM D 648): >500°F (>260°C) @ 264 psi
Note: Materials above 446°F (230°C) are considered suitable for "eutectic" reflow soldering, above 500°F (260°C) for
"lead-free" reflow soldering.
CertificateofCompliance:
This is to Certify that the product described above is manufactured to Mill-Max quality standards in accordance with all
applicable specifications and drawing. Mill-Max certifies this product to be free from defects of materials and workmanship.
This Certificate of Compliance covers the following requirements:
Dimensional (all features verified to be within tolerances described on the applicable drawing).
Raw Material (materials and properties verified to be as described on the applicable drawing).
Plating (platings as required, thickness verified, and performance including solderability per mil-standard).
Performance (insertion extraction or other force requirements as described on the applicable drawing).
Mill-Max Mfg. Corp. Datasheet — Last Modified 2/23/2011
Page 1 of 2
