Product catalogue | Sensor-Actuator-Interface (SAI) | SAI - lines & plug-in connectors | Valve plug | Type A | Type A |
SAIL-VSA
- 1 -
General ordering data
Order No.
9457711000
Part designation
SAIL-VSA-10U
Version
Valve plugs, One end without connector - valve
plug, A, Socket
EAN
4032248229390
Qty.
1 pc(s).
Technical data
Ambient temperature, max.
80 °C
Ambient temperature, min.
-25 °C
Cable diameter, min
6 mm
Connection cross-section
0.75
Contact gap, valve plug
18 mm
Contact surface
tinned
Contact tube diameter
Miscellaneous
Core cross-section
0.75 mm
Material
PUR
Protection class
IP 67
Rated current
4 A
Rated voltage
24 V
Sheathing colour
grey
No. of poles
3
Version
One end without connector - valve plug
Cable length
10 m
Classifications
ETIM 2.0
EC000304
ETIM 3.0
EC001855
eClass 4.1
27-26-07-01
eClass 5.0
27-26-07-01
eClass 5.1
27-26-07-01
