25–31 GHz Amplifier
AA028P2-99
2
Alpha Industries, Inc. [781] 935-5150
Fax [617] 824-4579 Email sales@alphaind.com www.alphaind.com
Specifications subject to change without notice. 2/00A
Characteristic
Value
Operating Temperature (TC)
-55°C to +90°C
Storage Temperature (TST)
-65°C to +150°C
Bias Voltage (VD1)7 VDC
Power In (PIN)
13 dBm
Absolute Maximum Ratings
Gain vs. Frequency
20
25
30
35
Frequency (GHz)
Gain
(dB)
0
5
10
15
20
-55C
+85C
+25C
Output Power vs. Frequency
Frequency (GHz)
P
1
dB
(dBm)
10
12
14
16
18
20
25
27
29
31
Return Loss vs. Frequency
-15
-10
-5
0
20
25
30
35
Frequency (GHz)
Return
Loss
(dB)
S11
S22
Typical Performance Data
Outline
AA028P2-99
YYWW
0.022
(0.56 mm)
0.180
(4.57 mm)
0.090 (2.29 mm)
0.028
(0.71 mm)
0.057
(1.45 mm)
0.008
(0.20 mm)
0.011
(0.28 mm)
0.295 (7.49 mm)
0.225 (5.72 mm)
PIN 1
IDENTIFICATION
