AD7890
–20–
REV. A
P
C
OUT LINE DIME NSIONS
Dimensions shown in inches and (mm).
Plastic DIP (N-24)
PIN 1
24
1
13
12
0.260
±
0.001
(6.61
±
0.03)
0.32 (8.128)
0.30 (7.62)
0.011 (0.28)
0.009 (0.23)
15
°
0
NOTES
1. LEAD NO. 1 IDENTIFIED BY DOT OR NOTCH
2. PLASTIC LEADS WILL BE EITHER SOLDER DIPPED OR TIN PLATED
IN ACCORDANCE WITH MIL-M-38510 REQUIREMENTS.
0.02 (0.5)
0.016 (0.41)
0.130 (3.30)
0.128 (3.25)
0.07 (1.78)
0.05 (1.27)
SEATING
PLANE
1.228 (31.19)
1.226 (31.14)
0.11 (2.79)
0.09 (2.28)
Cerdip (Q-24)
PIN 1
1
24
12
13
0.295 (7.493)
MAX
15
°
0
°
0.320 (8.128)
0.290 (7.366)
0.012 (0.305)
0.008 (0.203)
TYP
0.225
(5.715)
MAX
0.125
(3.175)
MIN
0.070 (1.778)
0.020 (0.508)
0.180
(4.572)
MAX
SEATING
PLANE
1.290 (32.77) MAX
0.021 (0.533)
0.015 (0.381)
TYP
0.065 (1.651)
0.055 (1.397)
TYP
0.110 (2.794)
0.090 (2.286)
TYP
1. LEAD NO. 1 IDENTIFIED BY DOT OR NOTCH.
2. CERDIP LEADS WILL BE EITHER TIN PLATED OR SOLDER DIPPED
IN ACCORDANCE WITH MIL-M-38510 REQUIREMENTS.
SOIC (R-24)
1
12
13
24
15.6 (0.614)
15.2 (0.598)
0.299 (7.6)
0.291 (7.4)
0.419 (10.65)
0.394 (10.00)
0.050 (1.27)
0.019 (0.49)
0.014 (0.35)
0.104 (2.65)
0.093 (2.35)
0.012 (0.3)
0.004 (0.1)
0.005 (1.27)
0.016 (0.40)
0.013 (0.32)
0.009 (0.23)
0° - 8°
0.03 (0.75)
0.01 (0.25)
