AD8170/AD8174
–4–
REV. 0
WARNING!
ESD SENSITIVE DEVICE
CAUTION
ESD (electrostatic discharge) sensitive device. Electrostatic charges as high as 4000 V readily
accumulate on the human body and test equipment and can discharge without detection.
Although the AD8170/AD8174 feature proprietary ESD protection circuitry, permanent damage
may occur on devices subjected to high energy electrostatic discharges. Therefore, proper ESD
precautions are recommended to avoid performance degradation or loss of functionality.
ABSOLUTE MAXIMUM RATINGS
1
Supply Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12.6 V
Internal Power Dissipation
2
AD8170 8-Lead Plastic (N) . . . . . . . . . . . . . . . . . 1.3 Watts
AD8170 8-Lead Small Outline (R) . . . . . . . . . . . 0.9 Watts
AD8174 14-Lead Plastic (N) . . . . . . . . . . . . . . . . 1.6 Watts
AD8174 14-Lead Small Outline (R) . . . . . . . . . . 1.0 Watts
Input Voltage (Common Mode) . . . . . . . . . . . . . . . . . . . .
±
V
S
Output Short Circuit Duration . . Observe Power Derating Curves
Storage Temperature Range
N & R Packages . . . . . . . . . . . . . . . . . . . . –65
°
C to +125
°
C
Lead Temperature Range (Soldering 10 sec) . . . . . . . .+300
°
C
NOTES
1
Stresses above those listed under “Absolute Maximum Ratings” may cause
permanent damage to the device. This is a stress rating only and functional
operation of the device at these or any other conditions above those indicated in
the operational section of this specification is not implied. Exposure to absolute
maximum rating conditions for extended periods may affect device reliability.
2
Specification is for device in free air: 8-Pin Plastic Package:
θ
= 90
°
C/Watt;
8-Pin SOIC Package:
θ
JA
= 160
°
C/Watt; 14-Pin Plastic Package:
θ
JA
= 90
°
C/Watt
14-Pin SOIC Package:
θ
JA
= 120
°
C/Watt, where P
D
= (T
J
–T
A
)/
θ
JA
.
ORDERING GUIDE
Temperature
Range
–40
°
C to +85
°
C
–40
°
C to +85
°
C
Package
Description
8-Pin Plastic DIP
8-Pin SOIC
Reel 8-Pin SOIC
14-Pin Plastic DIP
14-Pin Narrow SOIC R-14
Reel 14-Pin SOIC
Package
Option
N-8
SO-8
SO-8
N-14
Model
AD8170AN
AD8170AR
AD8170AR-REEL –40
°
C to +85
°
C
AD8174AN
AD8174AR
AD8174AR-REEL –40
°
C to +85
°
C
AD8170-EB
AD8174-EB
–40
°
C to +85
°
C
–40
°
C to +85
°
C
R-14
Evaluation Board For AD8170R
Evaluation Board For AD8174R
MAXIMUM POWER DISSIPATION
The maximum power that can be safely dissipated by the
AD8170 and AD8174 is limited by the associated rise in
junction temperature. The maximum safe junction temperature
for plastic encapsulated devices is determined by the glass
transition temperature of the plastic, approximately +150
°
C.
Exceeding this limit temporarily may cause a shift in parametric
performance due to a change in the stresses exerted on the die
by the package. Exceeding a junction temperature of +175
°
C
for an extended period can result in device failure.
While the AD8170 and AD8174 are internally short circuit
protected, this may not be sufficient to guarantee that the maxi-
mum junction temperature (+150
°
C) is not exceeded under all
conditions. To ensure proper operation, it is necessary to observe
the maximum power derating curves shown in Figures 2 and 3.
M
AMBIENT TEMPERATURE –
°
C
2.0
1.5
0
90
–40 –30 –20 –10
0
10
20
30
50
60
70
80
40
1.0
0.5
8-PIN MINI-DIP PACKAGE
8-PIN SOIC PACKAGE
T
J
= +150
°
C
Figure 2. AD8170 Maximum Power Dissipation vs.
Temperature
AMBIENT TEMPERATURE –
°
C
2.5
2.0
0.5
–50
90
–40
M
–30 –20 –10
0
10 20
30
40 50
60
80
1.5
1.0
70
14-PIN SOIC
14-PIN DIP PACKAGE
T
J
= +150
°
C
Figure 3. AD8174 Maximum Power Dissipation vs.
Temperature
