AD8341
ABSOLUTE MAXIMUM RATINGS
Table 2.
Parameters
Supply Voltage VPRF, VPS2
DSOP
IBBP, IBBM, QBBP, QBBM
RFOP, RFOM
RF Input Power at Maximum Gain
(RFIP or RFIM, Single-Ended Drive)
Equivalent Voltage
Internal Power Dissipation
θ
JA
(With Pad Soldered to Board)
Maximum Junction Temperature
Operating Temperature Range
Storage Temperature Range
Lead Temperature Range (Soldering 60 sec)
Rev. 0 | Page 4 of 20
Rating
5.5 V
5.5 V
2.5 V
5.5V
13 dBm, re: 50
2.8 V p-p
825 mW
59 °C/W
125°C
40°C to +85°C
65°C to +150°C
300°C
Stresses above those listed under Absolute Maximum Ratings
may cause permanent damage to the device. This is a stress
rating only; functional operation of the device at these or any
other conditions above those indicated in the operational
section of this specification is not implied. Exposure to absolute
maximum rating conditions for extended periods may affect
device reliability.
ESD CAUTION
ESD (electrostatic discharge) sensitive device. Electrostatic charges as high as 4000 V readily accumulate on the
human body and test equipment and can discharge without detection. Although this product features proprie-
tary ESD protection circuitry, permanent damage may occur on devices subjected to high energy electrostatic
discharges. Therefore, proper ESD precautions are recommended to avoid performance degradation or loss of
functionality.
