9- and 11-Channel, Muxed Input
LCD Reference Buffers
AD8509/AD8511
FEATURES
Single-supply operation: 3.3 V to 6.5 V
High output current: 300 mA
Low supply current: 6 mA
Stable with 1000 pF loads
Pin-compatible with LMC6009
Pin-compatible with CL-FP6131
48-lead, Pb-free, TSSOP package
Rev.
B
Information furnished by Analog Devices is believed to be accurate and reliable.
However, no responsibility is assumed by Analog Devices for its use, nor for any
infringements of patents or other rights of third parties that may result from its use.
Specifications subject to change without notice. No license is granted by implication
or otherwise under any patent or patent rights of Analog Devices. Trademarks and
registered trademarks are the property of their respective owners.
Tel: 781.329.4700Fax: 781.326.8703
www.analog.com APPLICATION
LCD line inversion gamma references
FUNCTIONAL BLOCK DIAGRAM
0
INA1
INB1
INA2
INB2
INA11
INB11
A/B
VO11
VO2
VO1
Figure 1.
GENERAL DESCRIPTION
The AD8509 and AD8511 are 9-channel and 11-channel LCD
reference buffers, respectively, designed to drive 64 gray scale
column drivers. Each buffer has an A/B input to select between
two voltages for LCD displays. These buffers drive the resistor
ladders of LCD column drivers for gamma correction. These
LCD drivers have higher slew rates and higher output drive
currents than similar competitive parts. This increases the
stability of the reference ladder, resulting in better gray scale
and visual performance.
The AD8509 and AD8511 are specified over the 40°C to +85°C
temperature range. They are available in 48-lead, thin shrink
small outline (TSSOP), surface-mount, Pb-free packages in tape
and reel.
PIN CONFIGURATIONS
NC = NO CONNECT
14
13
12
11
10
9
8
1
2
3
4
7
6
5
19
18
17
16
15
20
23
22
21
24
29
28
27
32
31
30
40
39
38
37
36
35
34
33
26
25
41
42
43
44
45
46
47
48
NC
VO1
NC
NC
V
CC
GND
VO2
VO3
VO4
VO5
V
CC
GND
VO6
VO7
VO8
VO9
VO10
GND
V
CC
A/B
NC
INA1
INB1
INA2
INB2
INA3
INB3
INA4
INB4
INA5
INB5
INA6
INB6
INA7
INB7
INA8
INB8
INA9
INB9
INA10
NC
NC
VO11
NC
INB10
NC
INA11
INB11
AD8511
TOP VIEW
(Not to Scale)
NC = NO CONNECT
14
13
12
11
10
9
8
1
2
3
4
7
6
5
19
18
17
16
15
20
23
22
21
24
29
28
27
32
31
30
40
39
38
37
36
35
34
33
26
25
41
42
43
44
45
46
47
48
NC
NC
NC
NC
V
CC
GND
VO1
VO2
VO3
VO4
V
CC
GND
VO5
VO6
VO7
VO8
VO9
GND
V
CC
A/B
NC
NC
NC
INA1
INB1
INA2
INB2
INA3
INB3
INA4
INB4
INA5
INB5
INA6
INB6
INA7
INB7
INA8
INB8
INA9
NC
NC
NC
NC
INB9
NC
NC
NC
AD8509
TOP VIEW
(Not to Scale)
0
Figure 2. AD8509 and AD8511 48-Lead TSSOP (RU Suffix)
