參數資料
| 型號： | AD8605ARTZ-REEL7 |
| 廠商： | ANALOG DEVICES INC |
| 元件分類： | 運動控制電子 |
| 英文描述： | Precision Low noise CMOS Rail-to-Rail Input/Output Operational Amplifiers |
| 中文描述： | OP-AMP, 750 uV OFFSET-MAX, 10 MHz BAND WIDTH, PDSO5 |
| 封裝： | ROHS COMPLIANT, MO-178AA, SOT-23, 5 PIN |
| 文件頁數： | 6/20頁 |
| 文件大小： | 559K |
| 代理商： | AD8605ARTZ-REEL7 |
AD8605/AD8606/AD8608
ABSOLUTE MAXIMUM RATINGS
Stresses above those listed under Absolute Maximum Ratings
may cause permanent damage to the device. This is a stress
rating only; functional operation of the device at these or any
other conditions above those listed in the operational sections
of this specification is not implied. Exposure to absolute
maximum rating conditions for extended periods may affect
device reliability.
Table 3.
Parameter
Supply Voltage
Input Voltage
Differential Input Voltage
Output Short-Circuit Duration
to GND
Storage Temperature Range
All Packages
Operating Temperature Range
AD8605/AD8606/AD8608
Junction Temperature Range
All Packages
Lead Temperature Range
(Soldering, 60 sec)
Rev. D | Page 6 of 20
Rating
6 V
GND to V
S
6 V
Observe Derating Curves
65°C to +150°C
40°C to +125°C
65°C to +150°C
300°C
Table 4. Package Type
Package Type
5-Bump MicroCSP (CB)
5-Lead SOT-23 (RT)
8-Lead MSOP (RM)
8-Lead SOIC (R)
14-Lead SOIC (R)
14-Lead TSSOP (RU)
θ
JA1
220
230
210
158
120
180
θ
JC
220
92
45
43
36
35
Unit
°C/W
°C/W
°C/W
°C/W
°C/W
°C/W
1
θ
JA
is specified for worst-case conditions, i.e.,
θ
JA
is specified for device in
socket for PDIP packages;
θ
JA
is specified for device soldered onto a circuit
board for surface-mount packages.
ESD CAUTION
ESD (electrostatic discharge) sensitive device. Electrostatic charges as high as 4000 V readily accumulate on
the human body and test equipment and can discharge without detection. Although this product features
proprietary ESD protection circuitry, permanent damage may occur on devices subjected to high energy
electrostatic discharges. Therefore, proper ESD precautions are recommended to avoid performance
degradation or loss of functionality.
