AD8616/AD8618
ABSOLUTE MAXIMUM RATINGS
Table 3. AD8616/AD8618 Stress Ratings
Parameter
Supply Voltage
Input Voltage
Differential Input Voltage
Ouput Short-Circuit Duration to GND
Storage Temperature
Operating Temperature Range
Lead Temperature Range (Soldering 60 sec)
Junction Temperature
Rev. A | Page 5 of 16
Rating
6 V
GND to V
S
±3 V
Indefinite
–65°C to +150°C
–40°C to +125°C
300°C
150°C
Stresses above those listed under Absolute Maximum Ratings
may cause permanent damage to the device. This is a stress
rating only; functional operation of the device at these or any
other conditions above those indicated in the operational
section of this specification is not implied. Exposure to absolute
maximum rating conditions for extended periods may affect
device reliability.
THERMAL RESISTANCE
θ
JA
is specified for the worst-case conditions, i.e., θ
JA
is specified
for device soldered in circuit board for surface-mount packages.
Table 4.
Package Type
θ
JA
8-Lead MSOP (RM)
210
8-Lead SOIC (R)
158
14-Lead SOIC (R)
120
14-Lead TSSOP (RU)
180
θ
JC
45
43
36
35
Unit
°C/W
°C/W
°C/W
°C/W
ESD CAUTION
ESD (electrostatic discharge) sensitive device. Electrostatic charges as high as 4000 V readily accumulate on
the human body and test equipment and can discharge without detection. Although this product features
proprietary ESD protection circuitry, permanent damage may occur on devices subjected to high energy
electrostatic discharges. Therefore, proper ESD precautions are recommended to avoid performance
degradation or loss of functionality.
