參數資料
| 型號： | AD8698AR-REEL |
| 廠商： | ANALOG DEVICES INC |
| 元件分類： | 運動控制電子 |
| 英文描述： | Dual Precision, Rail-to-Rail Output Operational Amplifier |
| 中文描述： | DUAL OP-AMP, 300 uV OFFSET-MAX, 1 MHz BAND WIDTH, PDSO8 |
| 封裝： | MS-012AA, SOIC-8 |
| 文件頁數： | 1/20頁 |
| 文件大小： | 317K |
| 代理商： | AD8698AR-REEL |
Dual Precision, Rail-to-Rail Output
Operational Amplifier
AD8698
FEATURES
Low offset voltage: 100 μV max
Low offset voltage drift: 2
μV/°C max
Low input bias current: 700 pA max
Low noise: 8 nV/
√
Hz
High common-mode rejection: 118 dB min
Wide operating temperature:
40°C to +85°C
No phase reversal
APPLICATIONS
Photodiode amplifier
Sensors and controls
Multipole filters
Integrator
Rev.
0
Information furnished by Analog Devices is believed to be accurate and reliable.
However, no responsibility is assumed by Analog Devices for its use, nor for any
infringements of patents or other rights of third parties that may result from its use.
Specifications subject to change without notice. No license is granted by implication
or otherwise under any patent or patent rights of Analog Devices. Trademarks and
registered trademarks are the property of their respective owners.
One Technology Way, P.O. Box 9106, Norwood, MA 02062-9106, U.S.A.
Tel: 781.329.4700
Fax: 781.326.8703
GENERAL DESCRIPTION The AD8698 is a high precision, rail-to-rail output, low noise,
low input bias current operational amplifier. Offset voltage is a
respectable 100 μV max and drift over temperature is below
2 μV/°C, eliminating the need for manual offset trimming. The
AD8698 is ideal for high impedance sensors, minimizing offset
errors due to input bias and offset currents.
The rail-to-rail output maximizes dynamic range in a variety of
applications, such as photodiode amplifiers, DAC I/V
amplifiers, filters, and ADC input amplifiers.
The AD8698 dual amplifiers are offered in 8-lead MSOP and
narrow 8-lead SOIC packages. The MSOP version is available
in tape and reel only.
CONNECTION DIAGRAMS
8-Lead SOIC
(R-8)
OUT A
1
–IN A
2
+IN A
3
V–
4
V+
8
OUT B
7
–IN B
6
+IN B
5
AD8698
TOP VIEW
(Not to Scale)
0
8-Lead MSOP
(RM-8)
OUT A
1
–IN A
2
+IN A
3
V–
4
V+
8
OUT B
7
–IN B
6
+IN B
5
AD8698
TOP VIEW
(Not to Scale)
0
Figure 1.
