AD9816
–6–
REV. A
CAUTION
ESD (electrostatic discharge) sensitive device. Electrostatic charges as high as 4000 V readily
accumulate on the human body and test equipment and can discharge without detection.
Although the AD9816 features proprietary ESD protection circuitry, permanent damage may
occur on devices subjected to high energy electrostatic discharges. Therefore, proper ESD
precautions are recommended to avoid performance degradation or loss of functionality.
ABSOLUTE MAXIMUM RATINGS*
With
Respect
To
Parameter
Min
Max
Units
VIN, VREF
PGA Outputs
Clock Inputs
AVDD
DVDD
DRVDD
AVSS
Digital Outputs
Digital Inputs
Junction Temperature
Storage Temperature
Lead Temperature
(10 sec)
AVSS
AVSS
DVSS
AVSS
DVSS
DRVSS
DVSS
DRVSS
DVSS
–0.3
–0.3
–0.3
–0.5
–0.5
–0.5
–0.3
–0.3
–0.3
AVDD + 0.3
AVDD + 0.3
DVDD + 0.3
+6.5
+6.5
+6.5
+0.3
DRVDD + 0.3
DVDD + 0.3
+150
+150
V
V
V
V
V
V
V
V
V
°
C
°
C
–65
+300
°
C
*Stresses above those listed under Absolute Maximum Ratings may cause perma-
nent damage to the device. This is a stress rating only; functional operation of the
device at these or other conditions above those indicated in the operational sections
of this specification is not implied. Exposure to absolute maximum ratings for
extended periods may affect device reliability.
ORDERING GUIDE
Temperature
Range
Package
Description
Package
Option
Model
AD9816JS
AD9816JS-80010
AD9816-EB
0
°
C to +70
°
C
0
°
C to +70
°
C
44-Lead MQFP (Metric) Plastic Quad Flatpack
44-Lead MQFP (Metric) Plastic Quad Flatpack
Evaluation Board
S-44
S-44
WARNING!
ESD SENSITIVE DEVICE
