1. General description
The ADC1610S is a single-channel 16-bit Analog-to-Digital Converter (ADC) optimized for
high dynamic performance and low power consumption at sample rates up to 125 Msps.
Pipelined architecture and output error correction ensure the ADC1610S is accurate
enough to guarantee zero missing codes over the entire operating range. Supplied from a
single 3 V source, it can handle output logic levels from 1.8 V to 3.3 V in CMOS mode,
because of a separate digital output supply. It supports the Low Voltage Differential
Signaling (LVDS) Double Data Rate (DDR) output standard. An integrated Serial
Peripheral Interface (SPI) allows the user to easily configure the ADC. The device also
includes a programmable full-scale SPI to allow a flexible input voltage range from
1 V to 2 V (peak-to-peak). With excellent dynamic performance from the baseband to
input frequencies of 170 MHz or more, the ADC1610S is ideal for use in communications,
imaging and medical applications.
2. Features and benefits
SNR, 72.5 dBFS; SFDR, 88 dBc
Sample rate up to 125 Msps
16-bit pipelined ADC core
Clock input divided by 2 for less jitter
Single 3 V supply
Flexible input voltage range: 1 V (p-p) to
2 V (p-p)
CMOS or LVDS DDR digital outputs
HVQFN40 package
3. Applications
Wireless and wired broadband
communications
Spectral analysis
Ultrasound equipment
ADC1610S series
Single 16-bit ADC; 65 Msps, 80 Msps, 105 Msps or 125 Msps;
CMOS or LVDS DDR digital outputs
Rev. 3 — 25 January 2011
Product data sheet
Input bandwidth, 600 MHz
Power dissipation, 430 mW at 80 Msps
Serial Peripheral Interface (SPI)
Duty cycle stabilizer
Fast OuT-of-Range (OTR) detection
Offset binary, two’s complement, gray
code
Power-down and Sleep modes
Portable instrumentation
Imaging systems
Software defined radio
