1. General description
The ADC1613S is a single channel 16-bit Analog-to-Digital Converter (ADC) optimized for
high dynamic performance and low power at sample rates up to 125 Msps. Pipelined
architecture and output error correction ensure the ADC1613S is accurate enough to
guarantee zero missing codes over the entire operating range. Supplied from a 3 V source
for analog and a 1.8 V source for the output driver, it outputs data in serial mode via a
single differential lane, which complies with the JESD204A standard. The integration of
Serial Peripheral Interface allows the user to easily configure the ADCs and the serial
output modes. The device also includes a programmable full-scale SPI to allow a flexible
input voltage range from 1 V (p-p) to 2 V (p-p).
Excellent dynamic performance is maintained from the baseband to input frequencies of
170 MHz or more, making the ADC1613S ideal for use in communications, imaging, and
medical applications.
2. Features and benefits
SNR, 72.3 dBFS; SFDR, 88 dBc
Sample rates up to 125 Msps
Single channel, 16-bit pipelined ADC
core
3 V, 1.8 V power supplies
Flexible input voltage range:
1 V (p-p) to 2 V (p-p)
Serial output
3. Applications
Wireless and wired broadband
communications
Spectral analysis
Ultrasound equipment
ADC1613S series
Single 16-bit ADC; 65 Msps, 80 Msps, 105 Msps or 125 Msps;
serial JESD204A interface
Rev. 2 — 9 June 2011
Product data sheet
Input bandwidth, 600 MHz
Power dissipation, 550 mW at 80 Msps
SPI register programming
Duty cycle stabilizer
High Intermediate Frequency (IF)
capability
Offset binary, two’s complement, gray
code
Compliant with JESD204A serial
transmission standard
HVQFN32 package
Power-down mode and Sleep mode
Pin compatible with ADC1413S series,
ADC1213S series, and ADC1113S125
Portable instrumentation
Imaging systems
