ADDC02828SA–Typical EM Curves and Test Setup
REV. 0
–6–
+V
IN
–V
IN
+V
OUT
RETURN
CASE
LISN
1/4
0.1μF
GROUND PLANE
82nF
82nF
2μF
1
100μF
TWO METERS OF
TWISTED CABLE
NOTE: 100μF CAPACITOR AND 1
RESISTOR PROVIDE STABILIZATION FOR 100μH DIFFERENTIAL SOURCE INDUCTANCE
INTRODUCED BY THE LISNs. REFER TO SECTION ON EMI CONSIDERATIONS FOR MORE INFORMATION.
LISN
Figure 15. Schematic of Test Setup for EMI Measurements
FREQUENCY – MHz
130
0.01
0.0001
0.001
70
90
30
E
110
50
CONDUCTED EMISSIONS CE–101
CE101–1 4.5 AMPS
Figure 11. Conducted Emissions, MIL-STD-461D, CE101,
+28 V Hot Line 100 W Load
FREQUENCY – MHz
130
10
0.01
0.1
70
90
30
E110
50
1
CONDUCTED EMISSIONS CE–102
LIMIT 28VDC
Figure 12. Conducted Emissions, MIL-STD-461D, CE102,
+28 V Hot Line 100 W Load
FREQUENCY – MHz
166
0.1
0.0001
0.001
106
126
66
E146
86
0.01
RE101 MIL–STD–461D
RE101–1
Figure 13. Radiated Emissions, MIL-STD-461D, RE101,
100 W Load
FREQUENCY – MHz
90
10
0.01
0.1
30
50
–30
E
70
10
1
100
1000
RADIATED EMISSIONS RE–102
RE102–2
Figure 14. Radiated Emissions, MIL-STD-461D, RE102,
Vertical Polarity, 100 W Load
Note: Figures 11–15 were obtained from measurements on the ADDC02805SA, a single 5V dc output converter. Since the con-
struction and topology of the ADDC02828SA is almost identical to the ADDC02805SA, and the component values of the EMI
differential and common-mode filter in the ADDC02828SA are identical to the ADDC02805SA, the subject figures are shown here
as typical of the ADDC02828SA.
