REV. 0
ADF7011
–3–
Parameter
Min
Typ
Max
Unit
PHASE-LOCKED LOOP
VCO Gain 433 MHz/868 MHz
40/80
MHz/V @ 868 MHz
Phase Noise (In-Band)
5
433 MHz
Phase Noise (Out-of-Band)
6
Phase Noise (In-Band)
7
868 MHz
Phase Noise (Out-of-Band)
8
–81
–90
–83
–95
dBc/Hz @ 5 kHz offset
dBc/Hz @ 1 MHz offset
dBc/Hz @ 5 kHz offset
dBc/Hz @ 1 MHz offset
100 kHz loop BW
Spurious
9, 10
47–74, 87.5–118, 174–230, 470–862 MHz
9 kHz – 1 GHz
Above 1 GHz
Harmonics
10
Second Harmonic, 433 MHz/868 MHz
Third Harmonic, 433 MHz/868 MHz
Other Harmonics, 433 MHz/868 MHz
–54
–36
–30
dBm
dBm
dBm. Assumes external harmonic filter.
–23/–28
–25/–29
–26/–40
–20/–23
–22/–25
–23/–35
dBc
dBc
dBc
REFERENCE INPUT
Crystal Reference
433 MHz
868 MHz
External Oscillator
Frequency
Input Level, High Voltage
Input Level, Low Voltage
1.7
3.4
22.1184
22.1184
MHz
MHz
3.4
0.7 V
DD
40
MHz
V
V
0.2 V
DD
FREQUENCY COMPENSATION
Pull In Range of Register
1
100
ppm
PA CHARACTERISTICS
RF Output Impedance
868 MHz
433 MHz
16 – j33
25 – j2.6
, Z
REF
= 50
, Z
REF
= 50
TIMING INFORMATION
Chip Enabled to Regulator Ready
10
Crystal Oscillator to CLK
OUT
OK
4 MHz Crystal
22.1184 MHz Crystal
50
200
μ
s
1.8
2.2
ms
ms
TEMPERATURE RANGE – T
A
–40
+85
C
NOTES
1
Operating temperature range
is as follows: –40 C to +85 C.
2
Datarates should be limited to adhere to edge of band requirements in accordance with ETSI 300-220
3
Frequency Deviation = (PFD Frequency Mod Deviation )/2
.
GFSK Frequency Deviation = (PFD Frequency
4
The output power is limited by the spurious requirements of ETSI at +55 C. The addition of an output filter (see Applications section) will allow increased output
levels to >10 dBm at both 433 MHz and 868 MHz
5
V
DD
= 3 V, PFD = 4 MHz, PA = 10 dBm
6
V
DD
= 3 V, Loop Filter BW = 100 kHz
7
V
DD
= 3 V, PFD = 4.42368 MHz, PA = 3 dBm
8
V
= 3 V, Loop Filter BW = 100 kHz
9
These spurious levels are based on a maximum output power of +3 dBm for 868 MHz and +10 dBm for 433 MHz. It assumes a PFD frequency of <5 MHz.
Recommended PFD frequencies are 4.42368 MHz (22.1184/5) for 868 MHz, and 4 MHz for 433 MHz operation. Compliance for higher output powers will require
an external filter. See Applications section.
10
Not production tested. Based on characterization.
2
/2
where
m
= Mod Control.
Specifications subject to change without notice.
