ADG3231
–3–
CAUTION
ESD (electrostatic discharge) sensitive device. Electrostatic charges as high as 4000 V readily ac cu mu ate
on the human body and test equipment and can discharge without detection. Although the ADG3231
features proprietary ESD pro ec ion circuitry, permanent damage may occur on devices subjected to high
energy electrostatic discharges. Therefore, proper ESD pre cau ions are rec om mend ed to avoid per or mance
deg a da ion or loss of functionality.
ABSOLUTE MAXIMUM RATINGS
*
(T
A
= 25°C, unless otherwise noted.)
V
CC
to GND . . . . . . . . . . . . . . . . . . . . . . . . . . –0.3 V to +4.6 V
A1 Input Voltage . . . . . . . . . . . . . . . . . . . –0.3 V to V
CC1
+0.3 V
DC Output Current . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 mA
Operating Temperature Range
Industrial (B Version) . . . . . . . . . . . . . . . . . . –40°C to +85°C
Storage Temperature Range . . . . . . . . . . . . . –65°C to +150°C
Junction Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . .150°C
6-Lead SOT-23,
q
JA
Thermal Impedance . . . . . . . . . . . . . . . . . . . . . 229°C/W
Lead Temperature, Soldering (10 seconds) . . . . . . . . . . . 300°C
IR Reflow, Peak Temperature (<20 seconds) . . . . . . . . . . 235°C
*
Stresses above those listed under Absolute Maximum Ratings may cause permanent
damage to the device. This is a stress rating only; functional operation of the device
at these or any other conditions above those listed in the operational sections of this
specification is not implied. Exposure to absolute maximum rating conditions for
extended periods may affect device reliability. Only one absolute maximum rating
may be applied at any one time.
PIN CONFIGURATION
ADG3231
(Not to Scale)
V
A1
1
2
3
5
6
4
V
Y1
GND
NC
CC1
CC2
ORDERING GUIDE
Model Temperature Range Package Description Branding Package Option
ADG3231BRJ-REEL –40°C to +85°C SOT-23 W2B RJ-6
ADG3231BRJ-REEL7 –40°C to +85°C SOT-23 W2B RJ-6
PIN FUNCTION DESCRIPTIONS
Pin Mnemonic Description
1 V
CC1
Supply Voltage 1, can be any supply voltage from 1.65 V to 3.6 V.
2 NC Not Internally Connected.
3 A1
Digital Input Referred to V
CC1
.
4 GND Device Ground Pin.
5 Y1
Digital Output Referred to V
CC2
.
6 V
CC2
Supply Voltage 2, can be any supply voltage from 1.65 V to 3.6 V.
REV. 0
