ADM1021
–7–
REV. 0
The power-on default value of the Address Pointer Register is
00h, so if a read operation is performed immediately after power
on, without first writing to the Address Pointer, the value of the
local temperature will be returned, since its register address is
00h.
Value Registers
The ADM1021 has two registers to store the results of Local
and Remote temperature measurements. These registers are
written to by the ADC and can only be read over the SMBus.
Status Register
Bit 7 of the Status Register indicates that the ADC is busy con-
verting when it is high. Bits 5 to 3 are flags that indicate the
results of the limit comparisons.
If the local and/or remote temperature measurement is above
the corresponding high temperature limit or below the corre-
sponding low temperature limit, then one or more of these flags
will be set. Bit 2 is a flag that is set if the remote temperature
sensor is open-circuit. These five flags are NOR’d together, so
that if any of them is high, the
ALERT
interrupt latch will be set
and the
ALERT
output will go low. Reading the Status Register
will clear the five flag bits, provided the error conditions that
caused the flags to be set have gone away. While a limit com-
parator is tripped due to a value register containing an out-of-
limit measurement, or the sensor is open-circuit, the corresponding
flag bit cannot be reset. A flag bit can only be reset if the corre-
sponding value register contains an in-limit measurement, or the
sensor is good.
The
ALERT
interrupt latch is not reset by reading the Status
Register, but will be reset when the
ALERT
output has been
serviced by the master reading the device address, provided the
error condition has gone away and the Status Register flag bits
have been reset.
Table II. Status Register Bit Assignments
Bit
Name
Function
7
6
5
4
3
2
1–0
BUSY
LHIGH*
LLOW*
RHIGH*
RLOW*
OPEN*
1 When ADC Converting.
1 When Local High Temp Limit Tripped.
1 When Local Low Temp Limit Tripped.
1 When Remote High Temp Limit Tripped.
1 When Remote Low Temp Limit Tripped.
1 When Remote Sensor Open-Circuit.
Reserved.
*These flags stay high until the status register is read or they are reset by POR.
Configuration Register
Two bits of the configuration register are used. If Bit 6 is 0,
which is the power-on default, the device is in operating mode
with the ADC converting. If Bit 6 is set to 1, the device is in
standby mode and the ADC does not convert. Standby mode
can also be selected by taking the
STBY
pin low.
Bit 7 of the configuration register is used to mask the
ALERT
output. If Bit 7 is 0, which is the power-on default, the
ALERT
output is enabled. If Bit 7 is set to 1, the
ALERT
output is
disabled.
Table III. List of ADM1021 Registers
READ Address (Hex)
WRITE Address (Hex)
Name
Power-On Default
Not Applicable
00
01
02
03
04
05
06
07
08
Not Applicable
10
11
12
15
17
19
20
FE
FF
Not Applicable
Not Applicable
Not Applicable
Not Applicable
09
0A
0B
0C
0D
0E
0F
1
Not Applicable
13
14
16
18
Not Applicable
21
Not Applicable
Not Applicable
Address Pointer
Local Temp. Value
Remote Temp. Value
Status
Configuration
Conversion Rate
Local Temp. High Limit
Local Temp. Low Limit
Remote Temp. High Limit
Remote Temp. Low Limit
One-Shot
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Manufacturer Device ID
Die Revision Code
Undefined
0000 0000
0000 0000
Undefined
0000 0000
0000 0010
0111 1111
1100 1001
0111 1111
1100 1001 (C9h) (–55
°
C)
(00h)
(00h)
(00h)
(02h)
(7Fh) (+127
°
C)
(C9h) (–55
°
C)
(7Fh) (+127
°
C)
Undefined
2
Undefined
2
Undefined
2
1000 0000
2
Undefined
2
0000 0000
2
Undefined
0100 0001
Undefined
(41h)
NOTES
1
Writing to address 0F causes the ADM1021 to perform a single measurement. It is not a data register as such and it does not matter what data is written to it.
2
These registers are reserved for future versions of the device.
