ADP3025
ABSOLUTE MAXIMUM RATINGS
Table 2. ADP3025 Stress Ratings
Parameter
VIN to AGND
AGND to PGND
INTVCC
BST5, BST3 to PGND
BST5 to SW5
BST3 to SW3
CS5, CS3
SW3, SW5 to PGND
SD
DRVL5/3 to PGND
DRVH5/3 to SW5/3
All Other Inputs and Outputs
Rev. A | Page 5 of 24
Rating
–0.3 V to +27 V
±0.3 V
AGND – 0.3 V to +6 V
–0.3 V to +32 V
–0.3 V to +6 V
–0.3 V to +6 V
AGND – 0.3 V to VIN
–2 V to VIN + 0.3 V
AGND – 0.3 V to +27 V
–0.3 V to INTVCC + 0.3 V
–0.3 V to INTVCC + 0.3 V
AGND – 0.3 V to
INTVCC + 0.3 V
98°C/W
θ
JA
Operating Ambient Temperature
Range
Junction Temperature Range
Storage Temperature Range
Lead Temperature Range
(Soldering 10 sec)
0°C to 70°C
0°C to 150°C
–65°C to +150°C
300°C
Stresses above those listed under Absolute Maximum Ratings
may cause permanent damage to the device. This is a stress
rating only; functional operation of the device at these or any
other conditions above those listed in the operational sections
of this specification is not implied. Exposure to absolute
maximum rating conditions for extended periods may affect
device reliability.
ESD CAUTION
ESD (electrostatic discharge) sensitive device. Electrostatic charges as high as 4000 V readily
accumulate on the human body and test equipment and can discharge without detection. Although
this product features proprietary ESD protection circuitry, permanent damage may occur on devices
subjected to high energy electrostatic discharges. Therefore, proper ESD precautions are
recommended to avoid performance degradation or loss of functionality.
