Specifications are subject to change without notice APT-DIN 3 DS0603
1
Measurement of: kW
9 selectable full-scales
in 9 intervals from 0 to 5 (range from 0,4kW to 3,6kW)
Degree of protection (front): IP 50
3 analogue outputs (0 to 10VDC)
Response time:
≤
50ms
Product Description
Model
Range code
System
Power supply
Rated outputs
Number of inputs
Calibration
Ordering Key
APT-DINAV53G3 2 1
Active power
with auxiliary power sup-
ply of 400VAC (phase-
phase connection). 9 mea-
suring ranges selectable in 9
intervals from 0 to 5 (measur-
transducer
ing range from 0,4 to 3,6kW)
The house is for DIN-rail
mounting
and ensures a
degree of protection (front)
of IP 50.
Energy Management
3-channel Power Transducer
Type APT-DIN
Type Selection
System
3:
Three phase system
(3 wires, balanced/
unbalanced load)
Range code
AV5:
400 VAC - 5,2 AAC
(max. 480 V (L-L) -
6,2 A) (standard)
Power supply
D:
230VAC –15+10%
50/60Hz
G:
400VAC
–
15+10%
50/60Hz
Rated outputs
3:
3 x (0 to 10VDC)
Number of inputs
2:
2 x (3-phase inputs)
Calibration
1 :
3600W.
Rated inputs
2 (3-phase inputs) for current
and voltage measurements
Accuracy
Active power
(@ 25
°
C ± 5
°
C, R.H.
≤
60%)
±3% rdg (cos
0.7 L/C,
0.5 to 1Ph)
Additional errors
Humidity
Input frequency
Magnetic field
Ripple
< 0.5%, 60% to 90% R.H.
< 0.5%, 50 to 60 Hz
< 0.5% @ 400 A/m
balanced load:
≤
1% accor-
ding to IEC 60688-1
and
EN 60 688-1
unbalanced load:
≤
5%
kW
Measurement
Ranges (impedances)
AV5:
400VAC (
≤
2W per channel)
5.2AAC (
≤
0.3 VA per channel)
48 to 62 Hz
Frequency range
Over-load protection
Continuous: voltage/current
For 1 s
Voltage:
Current:
1.2 x rated input
2 x rated input
20 x rated input
Input Specifications
Analogue outputs
Number of outputs
Range
Response time
Temperature drift
Load:
3 (one per channel)
0 to 10 VDC
≤
50 ms typical
±500 ppm/
°
C
≥
10 k
10 V output
Analogue outputs
Insulation
By means of optocouplers,
2000 V
output to
measuring input /
power supply
Output Specifications
