參數資料
型號: APT1608SURCK
廠商: Kingbright Corp
文件頁數: 2/5頁
文件大小: 226K
描述: LED 1.6X0.8MM 630NM RED CLR SMD
產品目錄繪圖: APT1608 Series Top
APT1608 Series Side
APT1608 Series
標準包裝: 1
顏色:
Millicandela 等級: 220mcd
正向電壓: 1.95V
電流 - 測試: 20mA
波長 - 主: 630nm
波長 - 峰值: 650nm
視角: 120°
透鏡類型: 透明
透鏡樣式/尺寸: 矩形,帶平頂,1.2mm x 0.8mm
封裝/外殼: 0603(1608 公制)
尺寸/尺寸: 1.60mm L x 0.80mm W
高度: 0.75mm
安裝類型: 表面貼裝
包裝: 標準包裝
產品目錄頁面: 2889 (CN2011-ZH PDF)
其它名稱: 754-1123-6
SPEC NO: DSAD0926 REV NO: V.14A DATE: MAR/16/2013 PAGE: 2 OF 5
APPROVED: WYNEC CHECKED: Allen Liu DRAWN: F.Cui ERP: 1203001764
Selection Guide
Notes:
1. ?/2 is the angle from optical centerline where the luminous intensity is 1/2 of the optical peak value.
2. Luminous intensity/ luminous Flux: +/-15%.
 *Luminous intensity value is traceable to the CIE127-2007 compliant national standards.
Absolute Maximum Ratings at TA=25癈
Electrical / Optical Characteristics at TA=25癈
Notes:
1.Wavelength: +/-1nm.
2. Forward Voltage: +/-0.1V.
3. Wavelength value is traceable to the CIE127-2007 compliant national standards.
Note:
1. 1/10 Duty Cycle, 0.1ms Pulse Width.
Part No.
Dice
Lens Type
Iv (mcd) [2]
@ 20mA
iewing
Angle [1]
Min.
Typ.
2?/2
APT1608SURCK
Hyper Red (AlGaInP)
Water Clear
120
230
*40
*80
120?/SPAN>
Symbol
Parameter
Device
Typ.
Max.
Units
Test Conditions
籶eak
Peak Wavelength
Hyper Red
645

nm
IF=20mA
籇 [1]
Dominant Wavelength
Hyper Red
630

nm
IF=20mA
敾1/2
Spectral Line Half-width
Hyper Red
28

nm
IF=20mA
C
Capacitance
Hyper Red
35

pF
VF=0V;f=1MHz
VF [2]
Forward Voltage
Hyper Red
1.95
2.5
V
IF=20mA
IR
Reverse Current
Hyper Red

10
uA
VR=5V
Parameter
Hyper Red
Units
Power dissipation
75
mW
DC Forward Current
30
mA
Peak Forward Current [1]
185
mA
Reverse Voltage
5
V
Operating Temperature
-40癈 To +85癈
Storage Temperature
-40癈 To +85癈
