052-6203
Rev
D
12-2005
APT20GT60KR(G)
TYPICAL PERFORMANCE CURVES
MAXIMUM RATINGS
All Ratings: T
C = 25°C unless otherwise specied.
STATIC ELECTRICAL CHARACTERISTICS
Characteristic / Test Conditions
Collector-Emitter Breakdown Voltage (V
GE = 0V, I C = 0.5mA)
Gate Threshold Voltage (V
CE = VGE, I C = 500A, Tj = 25°C)
Collector-Emitter On Voltage (V
GE = 15V, IC = 20A, Tj = 25°C)
Collector-Emitter On Voltage (V
GE = 15V, IC = 20A, Tj = 125°C)
Collector Cut-off Current (V
CE = 600V, VGE = 0V, Tj = 25°C)
2
Collector Cut-off Current (V
CE = 600V, VGE = 0V, Tj = 125°C)
2
Gate-Emitter Leakage Current (V
GE = ±20V)
Symbol
V
(BR)CES
V
GE(TH)
V
CE(ON)
I
CES
I
GES
Units
Volts
A
nA
Symbol
V
CES
V
GE
I
C1
I
C2
I
CM
SSOA
P
D
T
J,TSTG
T
L
APT20GT60KR(G)
600
±30
43
20
80
80A @ 600V
174
-55 to 150
300
UNIT
Volts
Amps
Watts
°C
Parameter
Collector-Emitter Voltage
Gate-Emitter Voltage
Continuous Collector Current @ T
C = 25°C
Continuous Collector Current @ T
C = 110°C
Pulsed Collector Current 1 @ T
C = 150°C
Switching Safe Operating Area @ T
J = 150°C
Total Power Dissipation
Operating and Storage Junction Temperature Range
Max. Lead Temp. for Soldering: 0.063" from Case for 10 Sec.
APT Website - http://www.advancedpower.com
CAUTION: These Devices are Sensitive to Electrostatic Discharge. Proper Handling Procedures Should Be Followed.
MIN
TYP
MAX
600
3
4
5
1.6
2.0
2.5
2.8
25
1000
±100
600V
APT20GT60KR
APT20GT60KRG*
*G Denotes RoHS Compliant, Pb Free Terminal Finish.
The Thunderblot IGBT is a new generation of high voltage power IGBTs. Using Non- Punch
Through Technology, the Thunderblot IGBT offers superior ruggedness and ultrafast
switching speed.
Low Forward Voltage Drop
High Freq. Switching to 150KHz
Low Tail Current
Ultra Low Leakage Current
RBSOA and SCSOA Rated
Thunderbolt IGBT
G
C
E
TO-220
