APTM100DUM90
AP
T
M
10
0DUM
90
–
R
ev
0
J
ul
y,
2004
APT website – http://www.advancedpower.com
1 – 6
D2
S
Q1
D1
S2
G2
Q2
G1
S1
D2
G1
S1
S
G2
D1
S2
Absolute maximum ratings
These Devices are sensitive to Electrostatic Discharge. Proper Handing Procedures Should Be Followed.
Symbol
Parameter
Max ratings
Unit
VDSS
Drain - Source Breakdown Voltage
1000
V
Tc = 25°C
78
ID
Continuous Drain Current
Tc = 80°C
59
IDM
Pulsed Drain current
312
A
VGS
Gate - Source Voltage
±30
V
RDSon
Drain - Source ON Resistance
90
m
PD
Maximum Power Dissipation
Tc = 25°C
1250
W
IAR
Avalanche current (repetitive and non repetitive)
25
A
EAR
Repetitive Avalanche Energy
50
EAS
Single Pulse Avalanche Energy
3000
mJ
VDSS = 1000V
RDSon = 90m max @ Tj = 25°C
ID = 78A @ Tc = 25°C
Application
AC Switches
Switched Mode Power Supplies
Uninterruptible Power Supplies
Features
Power MOS 7 MOSFETs
-
Low RDSon
-
Low input and Miller capacitance
-
Low gate charge
-
Avalanche energy rated
-
Very rugged
Kelvin source for easy drive
Very low stray inductance
-
Symmetrical design
-
M5 power connectors
High level of integration
Benefits
Outstanding performance at high frequency operation
Direct mounting to heatsink (isolated package)
Low junction to case thermal resistance
Low profile
Dual Common Source
MOSFET Power Module
