050-5982
Rev
C
9-2005
MAXIMUM RATINGS
All Ratings: T
C = 25°C unless otherwise specified.
STATIC ELECTRICAL CHARACTERISTICS
Symbol
BV
DSS
V
DS(ON)
I
DSS
I
GSS
g
fs
V
isolation
V
GS(TH)
Characteristic / Test Conditions
Drain-Source Breakdown Voltage (V
GS = 0V, ID = 250 A)
On State Drain Voltage 1 (I
D(ON) = 15A, VGS = 10V)
Zero Gate Voltage Drain Current (V
DS = 1000V, VGS = 0V)
Zero Gate Voltage Drain Current (V
DS = 800V, VGS = 0V, TC = 125°C)
Gate-Source Leakage Current (V
GS = ±30V, VDS = 0V)
Forward Transconductance (V
DS = 25V, ID = 15A)
RMS Voltage (60Hz Sinewave from terminals to mounting surface for 1 minute)
Gate Threshold Voltage (V
DS = VGS, ID = 50mA)
MIN
TYP
MAX
1000
7.5
9
40
1000
±400
5.5
7
2500
35
UNIT
Volts
A
nA
mhos
Volts
Symbol
V
DSS
I
D
V
GS
P
D
T
J,TSTG
T
L
Parameter
Drain-Source Voltage
Continuous Drain Current @ T
C = 25°C
Gate-Source Voltage
Total Device Dissipation @ T
C = 25°C
Operating and Storage Junction Temperature Range
Lead Temperature: 0.063" from Case for 10 Sec.
ARF1501
1000
30
±30
1500
-55 to 200
300
UNIT
Volts
Amps
Volts
Watts
°C
RF POWER MOSFET
N - CHANNEL ENHANCEMENT MODE
250V
750W
40MHz
The ARF1501 is an RF power transistor designed for very high power scientific, commercial, medical and industrial RF
power generator and amplifier applications up to 40 MHz.
Specified 250 Volt, 27.12 MHz Characteristics:
Output Power = 750 Watts.
Gain = 17dB (Class C)
Efficiency > 75%
High Performance Power RF Package.
Very High Breakdown for Improved Ruggedness.
Low Thermal Resistance.
Nitride Passivated Die for Improved Reliability.
ARF1501
CAUTION: These Devices are Sensitive to Electrostatic Discharge. Proper Handling Procedures Should Be Followed.
THERMAL CHARACTERISTICS
Symbol
R
θJC
R
θCS
Characteristic (per package unless otherwise noted)
Junction to Case
Case to Sink (Use High Efficiency Thermal Joint Compound and Planar Heat Sink Surface.)
MIN
TYP
MAX
0.12
0.09
UNIT
°C/W
D
S
G
Volts
ARF1501
BeO
1525-xx
DS
S
GS
S
APT Website - http://www.advancedpower.com
