ARF80001-a
Confidential Page 1 of 2
2.45GHz Transmitter/Receiver Switch
KEY FEATURES
RF frequency range : 2.35GHz to 2.65GHz
Supply voltage : 3V to 3.3V
Insertion loss : 3.0dB
Isolation: >32dB
2nd harmonic compression: 65dBc
3rd harmonic compression: 68dBc
Die size : 844um by 496um
Process : 0.18um RF CMOS
GENERAL DESCRIPTION
The
AF80001
is a high frequency, high isolation TX/RX switch. It operates at the
frequency of 2.35GHz to 2.65GHz. The device has an insertion loss of 3.0dB
and operates over a supply range of +3V to +3.3V.
The AF80001 features 2 integrated harmonic traps at 2
nd
and 3
rd
harmonic. The
2
nd
harmonic and 3
rd
harmonic compression is measured at 65dBc and 68dBc
respectively. The device also features very high port-to-port isolation at more
than 32dB.
APPLICATION
2.45GHz ISM Wireless LAN
ARF80001-a
IP SPECIFICATIONS
