參數資料
| 型號： | ASD15-48S12 |
| 廠商： | Electronic Theatre Controls, Inc. |
| 英文描述： | Isolated and Regulated 15 WATT Modular DC/DC Converters |
| 中文描述： | 隔離及規管15瓦模塊化直流/直流轉換器 |
| 文件頁數： | 2/3頁 |
| 文件大小： | 307K |
| 代理商： | ASD15-48S12 |
Isolated and Regulated 15 WATT Modular DC/DC Converters
asd15
series
WWW.asTROdYNE.COM
asTROdYNE Usa: 1-800-823-8082
asTROdYNE PaCIFIC: 886-2-26983458
asTROdYNE EUROPE: 353 51 561060
INPUT sPECIFICaTIONs
Input Voltage, Nominal
Input Voltage Ranges
Input Surge Voltage
12VDC
9-18
50V (12V Models),
*
100V (48V Models),
*
10 mS duration, min.
48VDC
20-75 VDC
OUTPUT sPECIFICaTIONs
Voltage and Current
Load Regulation
20% - FL
Line Regulation
Trim Range
Temperature Coefficient
Ripple/Noise(Single/Dual)
Overvoltage Protection
Voltage Stability
Transient Response
Short Circuit Protection
See Selection Chart
singles: +/- 0.5%
duals: +/-1%, +/-3% (5V mod)
singles: +/- 0.5%
duals: +/- 1%
0.5V min, 0.65V typ
+/-0.01%/°C
100mV Pk-Pk, typ
Clamp, 130-150%
*
+/- 0.05%, max
+/- 2%, max
Continuous, self-recovering
GENERaL sPECIFICaTIONs
On/Off Control
Shutdown Idle Current
Input-Out Isolation
In/Out Capacitance
Efficiency
Switching Frequency
(Ref to - Input pin)
Logic “1”/Open=ON
Logic “0”/GND=OFF
15mA
1500VDC (48V)
500 VDC (12V)
1000 pF
82%, typ
450Khz
ENVIRONMENTaL sPECIFICaTIONs
Oper. Temperature
Storage Temperature
Maximum Case Temp
Input Fusing
MTBF
Shock/Vibration
-25 to +71°C(FL)
-40 to +125°C
*
110°C
*
12V: 4A, 48V: 2A
1,000,000 Hrs
Mil Std 217, 25°C
To MIL-STD 810°C
PHYsICaL sPECIFICaTIONs
Case Material
Construction
Weight
Aluminum
Fully Encapsulated
1.6 oz, (40g)
*
These are stress ratings. Exposure of the devices to any of these conditions
may adversely affect long term reliability. Proper operation under conditions
other than the standard operating conditions is neither warranteed nor implied.
All specifications are typical at nominal input, full load, and 25°C unless other-
wise noted
Astrodyne products are not authorized or warranteed for use
as critical components in life support systems, equipment used
in hazardous environments, nuclear controls systems, or other
mission-critical applications.
