1
622 Mbps Single Mode SFF LC Transceiver
C-1X-622C-F(DFB)-SLC(4)
20550 Nordhoff St. Chatsworth, CA 91311 tel: 818.773.9044 fax: 818.576.9486
9F, No 81, Shui Lee Rd. Hsinchu, Taiwan, R.O.C. tel: 886.3.5169222 fax: 886.3.5169213
LUMNDS583-Jun2405
rev. A.2
LUMINENTOIC.COM
Features
Duplex LC Single Mode Transceiver
Small Form Factor Multi-soured 2 x 5 Pin Package
Complies with ITU-T/STM-4, OC-12
1310nm / 1550nm Wavelength, FP / DFB Laser
Single+3.3V Power Supply
LVPECL Differential Inputs and Outputs
LVTTL Signal Detection Output
Class 1 Laser International Safety Standard IEC 825 Compliant
Solder ability to MIL-STD-883, Method 2003
Pin coating is Sn/Pb with minimum 2% Pb content
Flammability to UL94V0
Humidity RH 5-85% (5-95% short term) to IEC 68-2-3
Complies with Bell core GR-468-CORE
Uncooled laser diode with MQW structure
ATM 622 Mbps Links application
SONET/SDH Equipment Interconnect application
Parameter
Symbol
Min.
Max.
Unit
Note
Power Supply Voltage
Vcc
0
3.6
V
Output Current
Iout
0
30
mA
Soldering Temperature
-
260
C
10 seconds on leads only
Storage Temperature
Tstg
-40
85
C
Absolute Maximum Rating
Parameter
Symbol
Min.
Typ.
Max.
Unit
Note
Power Supply Voltage
Vcc
3.1
3.3
3.5
V
Operating Temperature (Case)
Topr
-5
-
70
C
C-1X-622C-F(DFB)-SLC(4)
Operating Temperature (Case)
Topr
-40
-
85
C
C-1X-622C-F(DFB)-SLC(4)A
Data Rate
-
622
-
Mbps
Recommended Operating Condition
