COMPACT BENCH-TOP TYPE
REGULATED DC POWER SUPPLY
C3830
Compact Bench-top Type Multipurpose Power Supply
Multiple Outputs of
±
5 V,
±
15 V and High Voltage
SPECIFICATIONS
FEATURES
Compact bench-top type
Multiple outputs of
±
5 V,
±
15 V and high
voltage (-200 V to -1500 V)
High stability
Parameter
High Voltage Power Supply Section
±
15 V Power Supply Section
±
5 V Power Supply Section
Output Voltage
(-200 to -1500) V dc (variable)
±
(5.00
±
0.25) V dc (fixed)
±
(15.00
±
0.75) V dc (fixed)
Maximum Output Current
1 mA
500 mA
200 mA
Input Regulation
a
±
0.005 % Typ.
±
0.005 % Typ.
±
0.015 % Typ.
Load Regulation
b
±
0.01 % Typ.
±
0.5 % Typ.
±
0.5 % Typ.
Ripple/noise
c
0.005 %p-p Typ.
0.16 % p-p Typ.
Input Line Voltage
(100
±
10) V ac, (120
±
12) V ac, (230
±
23) V ac, (To be selected on order)
Dimensions
f
255 mm(W)
×
54 mm(H)
×
230 mm(D)
Weight
Approx. 2.8 kg
Input Line Voltage Frequency
50 Hz to 60 Hz
Power Consumption
d
Operating Temperature/
Humidity Range
e
Characteristics Guaranteed
Temperature/Humidity Range
e
Storage Temperature/
Humidity Range
e
Approx. 50 VA Max.
0
°
C to +40
°
C, 90 % RH Max.
0.06 %p-p Typ.
Drift
d
±
0.03 %/h Typ.
±
0.05 %/h Typ.
±
0.05 %/h Typ.
Temperature Coefficient
±
0.03 %/
°
C Typ.
±
0.03 %/
°
C Typ.
Two 4-pin receptacles
(HIROSE SR30-10R-4S)
—
—
—
—
±
0.03 %/
°
C Typ.
One 4-pin receptacle
(MIYAMA MC-032)
Output Receptacle
One SHV receptacle
High Voltage Output Monitor
High Voltage Output
Monitoring Accuracy
4-digit display
a
: For 10 % change in line voltage
b
: For 0 % to 100 % change in load
c
: At the maximum output
d
: After 30-minute warm-up
e
: Without moisture condensation
f
: Excluding projecting parts
+5
°
C to +35
°
C, 85 % RH Max.
-20
°
C to +50
°
C, 95 % RH Max.
±
0.5 % Typ.
The C3830 is a bench-top type multipurpose power supply
incorporating a high voltage power supply that provides maximum
output of -1.5 kV for a photomultiplier tube and constant voltage
power supplies that provide
±
5 V and
±
15 V for peripheral
devices such as Hamamatsu preamplifiers and photon counting
units. The four digit digital voltmeter on the front panel shows the
output value of high voltage with high accuracy.
Information furnished by HAMAMATSU is believed to be reliable. However, no responsibility is assumed for possible inaccuracies or omissions. Specifications are
subject to change without notice. No patent rights are granted to any of the circuits described herein. 1999 Hamamatsu Photonics K.K
Subject to local technical requirements and regulations, availability of products included in this promotional material may vary. Please consult with our sales office.
