Features
l
Single power supply (+5 V) operation
l
Operation with two input signals (M-CLK and M-RESET)
l
Compact: 48 × 56 mm
l
Assembled with low profile components
Applications
l
Various types of image acquisition
l
Optical detection equipment
P H O T O D I O D E
Driver circuit for photodiode array with amplifier
C9118 series
Compact, easy-to-use driver circuit
PRELIMINARY DATA
Jan. 2003
C9118 series CMOS driver circuit is designed for S8865 series photodiode array with amplifier.
C9118 series operates a linear image sensor by just inputting two signals (M-CLK and M-RESET) and a signal +5 V supply. C9118 series is
assembled on a compact board measuring 48 × 56 mm and allows downsizing of the measurement equipment.
C9118 is intended for single use or parallel connections, while C9118-01 is suitable for cascade connections.
C9118 series does not include S8865 series photodiode array with amplifier, so select the desired photodiode array and order it separately.
1
I
Absolute maximum ratings (Ta=25 °C)
Parameter
Supply voltage
Digital input voltage
Operating temperature
Storage temperature
*1: No condensation
Symbol
Vcc
-
Topr
Tstg
Value
+7
V
0 to 50 *
1
0 to 70 *
1
Unit
V
V
°C
°C
I
Specifications (Ta=25 °C)
Parameter
Rated voltage
Current consumption
Symbol
-
+Is
V
IH
V
IL
TpwstRESET1
f
CLK
t
TLH
/ t
THL
fV
Voffset
Vast
Min.
4.9
-
2.0
0
10
40
-
1
-
-
Typ.
5.0
65
-
-
-
-
20
-
0.5
4.0
Max.
5.2
75
V
0.8
-
4000
30
1000
-
-
Unit
V
mA
V
V
μs
kHz
ns
kHz
V
V
High level
Low level
Digital input
M-RESET pulse width (Low level)
M-CLK frequency
Digital rise/fall times
Data rate
Offset output
VIDEO saturation output *
2
*2: From offset value.
